Coupling camera – Welch Allyn RL-100 Rhinolaryngoscope - User Manual User Manual
Page 7
COUPLING CAMERA / ADAPTOR /
EYEPIECE COUPLER
*Attach the endoscope eyepiece coupler to the C-mount adaptor
by rotating the adaptor clockwise.
*Rotate the focus lock ring on the camera fully clockwise. Then
mount the coupler and C-mount adaptor to the camera by rotating
the assembly clockwise. Continue until no thread is exposed.
