CONNECTING THE CAMERA CONTROL UNIT
TO A MONITOR
Locate the S-VHS video cable. With the alignment groove of the
cable connector (identified with an arrow on the connector) posi-
tioned 90 degrees to the floor, push the connector into the recep-
tacle on the back of the camera control unit marked S-VIDEO
OUT. Align the remaining end in the same manner and connect it
to the receptacle on back of the monitor marked Y/C INPUT
VIDEO. The control unit is now connected to the monitor. To
view an image on the monitor make sure that the INPUT Y/C VTR
button on the front control panel of the monitor is depressed.
