Directions for use

Welch Allyn fiber optic laryngoscope handles

5

Autoclave instructions

NOTE: The main handle and bottom cap are compatible with these autoclave methods which
are provided for facilities who wish to autoclave after cleaning and intermediate level
disinfection.

Disassembly:

1. Disassemble the handle and remove batteries and

lamp cartridge per figures 3.

2. Set batteries and lamp cartridge aside.

After battery and lamp cartridge removal, select ONE of the following autoclave
methods below for the main handle and bottom cap:

Gravity autoclave: Follow equipment manufacturer and facility procedures in the
set-up and operation of autoclave equipment. Gravity autoclave settings are as
follows:

Temperature: 132 C (270 F)

• Exposure

time:

3

minutes

(unwrapped)

• Minimum

dry

time:

1

minute

Pre-vacuum autoclave: Follow equipment manufacturer and facility procedures in the
set-up and operation of autoclave equipment. Pre-vacuum autoclave settings are as
follows:

Temperature: 132 C (270 F)

• Exposure

time:

3

minutes

(unwrapped)

• Minimum

dry

time:

1

minute

Maintenance,
Inspection and Testing

1. Inspect each component area (per figure 2) for damage or

deterioration.

WARNING: Discard any component that shows

evidence of damage or deterioration.

Contact Welch Allyn for component replacement.

2. Reassemble (per figure 4) with new or batteries in known

good condition.

3. Attach handle to a clean and disinfected test blade

assembly in known working condition. Verify that:

Blade assembly engages and locks onto handle.

Blade assembly deploys into its locked position on
handle AND lamp illuminates.

• Light

output

is

satisfactory.

If the lamp fails to light or output is low, check or
replace the lamp and/or batteries

Storage: Store

handle

per

facility

practice to allow device to remain

clean, dry, and ready for service.
