4

Directions for use

Welch Allyn rechargeable fiber optic and standard

laryngoscope

handles

Maintenance instructions

Battery charging instructions


WARNING: Power output from rechargeable batteries can fall rapidly during use. Always fully
re-charge batteries between each use.


CAUTION: Use only Welch Allyn batteries. Use handles with appropriate batteries as shown in

Table 1.

Table 1: Replacement Battery and Lamp Part Numbers

Handle REF

Number

Type

Battery REF Number

Total Run

Time*

Lamp REF

Number

60710

Standard

72000, 2.5V 900mAh (2.3Wh)

1 hr

NA

60720

Standard

72000, 2.5V 900mAh (2.3Wh)

1 hr

NA

60713

Fiber Optic

72000, 2.5V 900mAh (2.3Wh)

1 hr

HPX060

60835

Fiber Optic

72200, 3.5V 620mAh (2.2Wh)

¾ hr

HPX003

* Total run time is estimated based on a fully charged battery

Standard handles: 60710 & 60720 (2.5v)

CAUTION: Use only with Welch Allyn REF: 71030, 71032, 71034, 71036, 71040 Charger.

1. Set up and operate the charger per the 710XX charger specifications (See Table 2).
2. After initial cleaning and disinfection, connect the handle(s) to the charger. See Figure 4.
3. Charge handle for approximately 16 hours or overnight to assure battery is fully charged.
4. After charging, continue maintenance, inspection, testing and intermediate level disinfection per

these instructions.


Table 2: 710XX Charger Specifications

Note: Welch Allyn Standard Laryngoscope handles REF 60710 & 60720 incorporate internal current
limitation.

Charger REF Number

Input Specification Output

Specification

71030

100V~50/60Hz 55mA

7.0VDC, 200mA

71032

230V~50Hz 25mA

7.5-9.2VDC, 200mA

71034

230V~50Hz 25mA

7.5-9.2VDC, 200mA

71036

240V~50Hz 30mA

9.2VDC, 100mA

71040

120V~60Hz 50mA

9.8VDC, 150mA
