Right side view, Components and connections – Vinten Radamec Fusion APS User Manual
Page 7
5
Components and Connections
Right Side View
4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Rotating laser scanner head
5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ethernet ports
6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power interconnecting cable
7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Data interconnecting cable
4
6
7
5
