10
I I . I n s t a l l a t i o n I n s t r u c t i o n s
 TEST THE UNIT BEFORE INSTALLING IT
1. Remove the unit from the box. SAVE THE BOX AND PACKING
MATERIALS.
2. Plug in the power cord and let the unit run on a hard, flat surface.
3. Check to make sure that both fans (one in the front and one at the rear of
the cooling unit) are blowing.
4. Check that the cooling unit is discharging cold air from the front (it should
be approximately 5° C colder than the temperature on the digital display)
 Cut a hole in the wall that is 5mm larger than the dimensions (W x H)
of the cooling unit, and create a frame to support the rear of the
cooling unit. The rear of the cooling unit should be supported by the wall
through which it is installed. Horizontal braces should be installed between the
studs below and above the cooling unit. If the studs in the wall must be cut to
accommodate the width of the cooling unit, vertical braces also should be
installed on either side of the cooling unit.
4200 Frame and Cut-Out Diagram (inches)
