www.whisperkool.com | Page 5

FAN SPEED REFERENCE

UNIT SPECIFICATIONS

Your fan speed selection will depend on the amount of heat that needs to be removed from the cellar and the ap-

plication of the unit (through a wall or fully ducted). Fan speed selection will depend on the cellar size, insulation

factor, door seal and desired wine temperature. When initially installing the unit, set the fan speed to High setting

for a quick chill down. Once the temperature of the cellar reaches the desired temperature, you may be able to select

a lower fan speed to handle the normal load. In the event the temperature outside goes above 90 degrees, (when

exhausting to the outside) you may need to select the higher fan speed.

* To get a feeling for decibels, a food blender at 3ft is 90 dBA, garbage disposal at 3ft is 85 dBA, vacuum cleaner at

10ft is 75 dBA, normal speech at 3ft is 79 dBA, dishwasher in the next room is 55dBA, Quiet night is 35dBA

Fully ducted units need to be set and stay in the High fan speed position.

Model

3500ti & 3500tiR

5000ti & 5000tiR

8000ti & 8000tiR

Cellar Size

800 cu. ft.

1250 cu. ft.

2000 cu.ft

Dimensions

14.25”W x 15.75”H x 28”D

14.25”W x 15.75”H x 28”D

14.25”W x 22”H x 28”D

Weight

115 lbs

115 lbs

150 lbs

AMPS

(running)

9

9

10

dBA

51 low 58 med 66 high

51 low 58 med 66 high

57 low 59 med 61 high

Installation

Through-the-Wall, Partially Ducted, Fully Ducted

Thermostat

Digital Control Display

Temp. Delta

55°F temperature differential

(maintains proper cellar temperature when exhaust environment does not exceed 110°F)

Outside Venting

Can be done if the outside temperature does not exceed 110°F, the external grille cover is

required.

Ducting Options

Unit can be fully ducted.

Warranty

2 year parts and labor / 5 year compressor

Model

3500ti & 3500tiR

5000ti & 5000tiR

8000ti & 8000tiR

Speed Selection

Low Med High Low Med High Low Med High

Air Flow

(CFM)

147

180

256

147

180

256

274

318

333

Sound

(dBA In Cellar / Out of Cellar)

51/51 58/57 66/65 51/51 58/57 66/65 57/57 59/59 60/61

Cooling Capacity

(BTU/h)

2374 2514 2688 3709 3928 4200 5140 5606 5760
