Quick reference guide – Vintage Cellars Extreme ti Series User Manual
Page 5
www.whisperkool.com | Page 3
QUICK REFERENCE GUIDE
Remote Front / Side View
Fully Ducted - Front / Side View
Rear
Controller w/Remote Box
Bottle Probe
Grille w/Filter
Control Panel
(see page 12 for details)
Compressor
Access Panel
Compressor
Access Panel
Fan Speed Control
Drain Port
Controller w/Remote Box
Bottle Probe
Return Plenum
Supply Plenum
Control Panel
(see page 12 for details)
Compressor
Access Panel
Fan Speed Control
Exhaust Plenum
Intake Plenum
Humidistat Connection
(Included with Built -in-
Humidity Option)
Humidistat Connection
(Included with Built -in-
Humidity Option)
Water Port
(Included with Built -in-
Humidity Option)
Water Port
(Included with Built -in-
Humidity Option)
