Quick reference guide, Front / side view rear / side view – Vintage Cellars Extreme ti Series User Manual
Page 4
EXti
033114
Page 2 | 1-800-343-9463
QUICK REFERENCE GUIDE
Front / Side View
Rear / Side View
Controller
Bottle Probe
Probe Input
Grille w/Filter
Control Panel
(see page 12 for details)
Humidistat Connection
(Included with Built -in-
Humidity Option)
Water Port
(Included with Built -in-
Humidity Option)
Compressor
Access Panel
Fan Speed Control
Grille w/Filter
Drain Port
Drain Line
Access
Rear Power Option
