Mounting the Reader
Astra User Guide
60
Mounting the Reader
for mounting hole locations and dimensions.
When mounting the Astra Reader it is recommend to use an NRTL approved VESA 100
mount, following the standard mounting procedure of the VESA mount referencing the
Astra mounting hole locations as shown in
.
Alternatively you can use the centered Tripod mounting hole for 1/4"- 20 screws. This is
for use with tripods shorter than one meter.
Figure 21:
Mounting the Reader
W A R N I N G !
To comply with FCC’s RF radiation exposure requirements, the antenna(s) used
for this transmitter must be installed such that a minimum separation distance
of 25cm is maintained between the radiator (antenna) & user’s/nearby people’s
body at all times and must not be co-located or operating in conjunction with
any other antenna or transmitter.
