Using GPIO
Astra User Guide
36
5.
GPIO Input (
GPIO_7
)
6.
GPIO Output (
GPIO_0
)
7.
GPIO Output (
GPIO_1
)
8.
GPIO Output (
GPIO_2
)
9.
GPIO Output (
GPIO_5
)
10.
Amber LED - Output
11.
Green LED - Output
12.
Isolated-GND
Note:
The values in parentheses indicate the enumeration used by the API and RQL for each
GPIO line.
