52
920i
Programming Reference
5.4
Program Scale
SubmitData
For
920i
indicators configured for program scale operation, passes data from a user program to the scale
processor. Weight, mode, and tare values are provided by the user program; the displayed weight is the weight
value minus tare. Gross/net mode is set by the gn parameter regardless of whether a tare value is passed. This
allows display of a net value when the net is known but gross and tare values are not available.
Note that because the user program supplies all weight data, weight data acquisition APIs are not valid for
program scales. When used with program scales, these APIs (including GetGross, GetNet, GetTare) will
typically return a SysCode value of SysInvalidScale. Always check the returned SysCode value of scale-related
APIs to ensure valid data.
Syntax:
function SubmitData (scale : Integer; weight : Real; gn : Mode; units : UnitType;
tare : Real) : SysCode;
SysCode values returned:
SysInvalidScale
The scale is not set up as a program scale.
SysOK
The function completed successfully.
SubmitDSPData
Submit data to a program scale. This function works much like SubmitData() but has fewer parameters. New to
this function is the dp : Decimal_Type that allows the program to set the decimal point for the display. The call
assumes Gross mode and primary units.
Syntax:
function SubmitDSPData( scale : integer; weight : real; units : string; dp :
Decimal_Type ) : SysCode;
SysCode values returned:
SysInvalidScale
The scale is not set up as a program scale.
SysOK
The function completed successfully.
5.5
Setpoints and Batching
Note
Unless otherwise stated, when an API with a VAR parameter returns a SysCode value other than SysOK,
the VAR parameter is not changed.
DisableSP
Disables operation of setpoint SP.
Method Signature:
function DisableSP (SP : Integer) : SysCode;
Parameters:
[in]
S
P
Setpoint number
SysCode values returned:
SysInvalidSetpoint
The setpoint specified by
SP
does not exist.
SysBatchRunning
Setpoint
SP
cannot be disabled while a batch is running.
SysInvalidRequest
The setpoint specified by
SP
cannot be enabled or disabled.
SysOK
The function completed successfully.
Example:
DisableSP (4);
EnableSP
Enables operation of setpoint SP.
Method Signature:
function EnableSP (SP : Integer) : SysCode;
