Multifunctional Monitor & Logger PowerLog 6S
Program flow chart
Monitor
>3 Seconds
Note: When you turn off the PowerLog6S it will remember the current screen and start from
that screen when next turned on again.
①
>3 Seconds
>3 Seconds
Data Log
“____” is shown in the upper right
corner blinkingly
Transfer data to USB port
Save data to the appointed Log File
>3 Seconds
③
>3 Seconds
④
Select Main Menu
Details in next page
PowerLog
POWER ON
TYPE
XXXXXXXXXX
LOGS
0
RATE
2.00S
[1988Kb/16h:34]
Logs OFF
S/N:XXXXXXXXXX
PowerLog6S
Ver X.X.X
www.hillrc.com
Note：
means if no operation on the button for 3 minutes, the system will return to monitor screen automatically.
Logo Screen
Inf. Screen
TACHOMETER
RPM
1200
Max
01250
Blade
03
5S
20.63V
▣
V
75mV
1
4.110V
2
4.152V
3
4.087V
4
4.162V
5
4.120V
6
------
T0
28.7
C
28.5 28.9
T1
27.1
C
25.8 30.7
T2
27.1
C
27.1 32.5
T3
NULL
C
NULL NULL
003015mAh 20m:10
10.50A
12.01V 126.1W
Freq.
50Hz
Period
20000us
+P
5.0% 1000us
-P
95.0% 19000us
------
<
>
<
>
<
>
<
>
CELLS MODE
⊙Difference
○Auto Differenc
○Each Voltage
TEMP SENSOR LIST
00000297e2D6
00000297d187
<▢>+<▼>
>3 Seconds
>3 Seconds
<
>
<▢>+<▼>
>3 Seconds
>3 Seconds
SELECT TYPE
⊙LiPo
○Lilo
○LiFe
○User1
○User2
○User3
○User4
○User5
ALARM SETTING
Cells Voltag
Pack Voltage
Timer Over
Current
Power
Capacity
Temperature
RPM
Period
Pulse
PACK VOLT ALARM
MAX.
60.00V
MIN.
0.000V
DIFF
60.00V
LiPo
Select
Rename
Alarm&Trigger
CELLS VOLT ALARM
MAX.
4.22V
MIN.
3.00V
DIFF
0.05V
TIME OVER ALARM
Minutes(0-99999)
120
②
Select Type
CURRENT ALARM
MAX.
130.0A
MIN.
-130 A
DIFF
260.0A
POWER ALARM
MAX.
7800W
MIN.
-7800W
DIFF
15600W
CAPACITY ALARM
(100-999900mAh)
999900
TEMP. ALARM
MAX.
125.0C
MIN.
-55.0C
DIFF
180.0C
RPM ALARM
MAX.
99990 RPM
MIN.
0 RPM
DIFF
99990 RPM
RERIOD ALARM
MAX.
999990us
MIN.
0 us
DIFF
999990us
PULSE ALARM
MAX.
999990us
MIN.
0 us
DIFF
999990us
<
>
Watt monitor
Cells monitor
Temperature monitor
Tachometer monitor
PWM monitor
