Losi LOSB0103 User Manual
Page 2
2
3
Introduction
We hope you operate this RC model in a safe, reasonable and cau-
tious fashion in order to enjoy your vehicle. Should you operate
this vehicle without a cautious and reasonable approach it may
result in serious injury and/or property damage. Only you can
control and make certain that safety precautions and instructions
are followed.
General:
•
THIS PRODUCT IS SUITABLE FOR CHILDREN 14 YEARS
OR OVER. THIS PRODUCT IS NOT A TOY. This product is
not intended for use by children without direct adult
supervision.
•
This RC vehicle is not intended for use on public highways
or roads.
•
Avoid an area that has many pedestrians or crowds
of people.
•
Keep in mind that this vehicle is radio controlled and
can experience moments of radio loss or interference, so
provide for a margin of error at all times.
•
Please be aware that the motor and batteries of this
RC vehicle will get HOT during each use. Be careful not
to burn yourself.
Electronic Speed Control (ESC):
•
Read all safety precautions prior to each use.
•
Never leave the vehicle/ESC unsupervised while it is
switched on, in use or connected to a power source. If
there is a short circuit or product defect, it could result in
fire.
•
If there are exposed wires, do not use the ESC until you
have installed shrink-wrap or replaced the wire.
•
Disconnect the battery from the ESC after use.
•
The ESC is not waterproof and should not be exposed
to moisture.
•
Do not attempt to use LiPo batteries or more than
6-cells NiMH batteries; doing so will damage the ESC
and could result in fire.
•
Always turn on the transmitter first then the ESC to
prevent an out-of-control vehicle.
•
When setting your Electronic Speed Controller:
º
Please disconnect motor or remove the pinion gear
during ESC setup or calibration functions.
º
Keep loose clothing, hair, gloves and fingers away
from moving parts at all times.
º
Rubber tires can cause severe injury if there is a
failure while running the vehicle while on a stand or
when being held. Ensure rubber tires are securely
mounted to the rims and if not, re-glue them and
check them often for security.
Introduction .................................................................................................2
Safety Precautions ......................................................................................3
Battery/Charging ........................................................................................3
Supplied and Required Equipment .....................................................4
Technical Overview ................................................................................5-7
ESC Overview/Troubleshooting ............................................................8
Transmitter Battery Installation .............................................................9
Vehicle Battery Installation ...................................................................10
Quick Start ..................................................................................................11
Losi 27MHz AM Radio System .......................................................12-13
Driving the 1/10 HIGHroller ..................................................................14
Tuning, Adjusting and Maintaining the 1/10 HIGHroller ....15-18
Troubleshooting your 1/10 HIGHroller .............................................19
Warranty Information ......................................................................20-21
RC Terminology .........................................................................................22
Parts Listing .........................................................................................23-24
Optional parts Listing ......................................................................24-25
Exploded Views ..................................................................................26-29
Stock Setup Sheet ....................................................................................30
Blank Setup Sheet ....................................................................................31
Introduction
Thank you for purchasing the Losi® 1/10 HIGHroller. We are
confident you will be satisfied with the performance of this
durable and resilient vehicle.
In the following pages you will find all the information you will
need to set up as well as operate your new 1/10 HIGHroller to
its full potential.
If you are an experienced RC hobbyist, or new to RC vehicles,
it will benefit you to read all enclosed information.
Register your Losi Product Online
Register your 1/10 HIGHroller now and be the first to find out
about the latest options parts, product updates and more.
Log on to WWW.LOSI.COM/REGISTER and follow the product
registration link to stay connected.
Losi/Horizon Support
If you have any questions concerning setup or operation of
your 1/10 HIGHroller, contact the appropriate Horizon Product
Support office.
Hours:
Monday thru Friday from 8:00am CST to 5:00pm CST
Getting Ready
Thoroughly read all the enclosed material, precautions and
follow instructions to avoid damaging your new RC vehicle. If
you choose to not follow these steps or instructions, it will be
considered negligence.
If after review of this manual and prior to running your 1/10
HIGHroller, you determine this RC vehicle is not what you
want—DO NOT proceed and DO NOT run the 1/10 HIGHroller.
If the 1/10 HIGHroller has been run, your local hobby shop will
not be able to process a return or accept it for exchange.
Batteries and Charging:
• Read all instructions provided by the manufacturer of the
batteries prior to use.
• Never leave the battery and charger unattended during use.
• Never allow minors to charge battery packs without adult
supervision.
• Never attempt to charge dead or damaged batteries.
• Never charge a battery if the cable has been pinched or
shorted.
• Never allow batteries or charger to come into contact with
moisture at any time
• Never charge batteries in extrememly hot or cold places
(recommended between 50--80 degrees Fahrenheit) or
place in direct sunlight.
• Always use only NiMH or NiCd rechargeable batteries.
Chargers cannot charge batteries such as “heavy duty,”
“Alkaline battery,” or “Mercury battery.”
• Always connect the positive red lead (+) and negative black
lead (-) terminals of the battery to the charger terminals
correctly.
• Always disconnect the battery and charger after charging and
let them cool between charges.
• Always inspect the battery before charging.
• Always make sure you know the specifications of the battery
to be charged or discharged to ensure it meets the
requirements of this charger.
• Never connect more than one battery pack to the charger at a
time.
• Always constantly monitor the temperature of the battery
pack while charging.
• Always end the charging process if the charger or battery
becomes hot to the touch or starts to change form during
the charge process.
When charging NiMH batteries, select a charger to meet
your requirements. Chargers can be of two primary types for
their source of power; a 100-240V wall charger, or one which
requires a 12V power supply. Follow the charger manufacturer’s
instructions and precautions during each use.
NOTICE
All instructions, warranties and other collateral documents are
subject to change at the sole discretion of Horizon Hobby, Inc.
For up-to-date product literature, visit
http://WWW.LOSI.COM/SUPPORT
Meaning of Special Language
The following terms are used throughout the product
literature to indicate various levels of potential harm when
operating this product:
NOTICE: Procedures, which if not properly followed, create a
possibility of physical property damage AND a little
or no possibility of injury.
WARNING: Procedures, which if not properly followed, create
the probability of property damage, collateral
damage, and serious injury OR create a high
probability of superficial injury.
WARNING: Read the ENTIRE instruction manual to become
familiar with the features of the product before
operating. Failure to operate the product correctly
can result in damage to the product, personal
property and cause serious injury.
This is a sophisticated hobby product and NOT a toy. It must be
operated with caution and common sense and requires some
basic mechanical ability. Failure to operate this Product in a
safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended
for use by children without direct adult supervision. Do not
attempt disassemble, use with incompatible components or
augment product in any way without the approval of Horizon
Hobby, Inc. This manual contains instructions for safety,
operation and maintenance. It is essential to read and follow all
the instructions and warnings in the manual, prior to assembly,
setup or use, in order to operate correctly and avoid damage or
serious injury.
Table of Contents
Safety Warnings and Precautions
