Technical Data
54 KISS-Stor 0/5 – User’s Manual
Technical Data
KISS-Stor 0/5 Specifications
Host Interface one SATA-I
Disk Interface SATA-I (support SATA-II but run in SATA-I)
RAID Levels
Supported
RAID level 0 and 5
Removable Drive
Carrier
3x SATA removable drive carrier
LED Indicators 3x disk activity LED indicators (red, yellow, green)
Operating Element Key to switch on/off the hard disks
Beeper Alarm Yes, built-in buzzer on board
FAN Rated speed: 4700RPM+/- 400RPM
Noise level: 35dB(A)
Hot Swap Yes
(Rebuilding for RAID 5 is transparent & automatic)
Dimensions W5.75 x D8.84 x H3.35 (inch)
W146 x D224.536 x H 85 (mm)
Weight Approx. 1.8 kg (3.96 lbs.)
Environmental Specifications
Ventilation cooling fan
Operating Temperature /
relative Humidity 0 … +50°C / 5 - 95 %, non-condensing
(32 … 122 °F / 5 - 95%, non-condensing)
Operating Altitude 3,048 m (10,000 ft)
