9. Starting Up KISS 1U Short – User’s Guide (V1.10)
9.
Starting Up
The rated voltage of the mains (AC) must agree with the voltage value on the type label.
9.1. AC-Power Cord Connection
The AC power plug of the PSU is located on the rear side of the KISS 1U Short platform.
Use the power cord suitable for the mains in your country.
Do not remove or alter the grounding prong on the power cord. In situations where a two-slot
receptacle is present, have it replaced with a properly grounded three-prong grounding type receptacle.
AC power plug
Fig. 22: KISS 1U Short (shown as system with AC-power connection)
1. Fig. 22).
2. Connect the other end of the AC power cord into a corresponding mains outlet for Class I equipment.
22 www.kontron.com
