7. Product Description
KISS 1U Short – User’s Guide (V1.10)
7.2. Rear Side
Fig. 10: Rear side of the KISS 1U Short with KTGM45/mITX motherboard
1
3
2
4
5
4
1
7
6
8
1
3
2
4
5
4
1
9
1
7
8
6
1
Fig. 11: Rear side of the KISS 1U Short with KTQM77/mITX motherboard
Legend for Fig. 10 and Fig. 11:
1 Fastening screws to secure the cover
2 Interfaces of the installed motherboard
3 2x PCI/PCIe free expansion card slots (for
configuration with KTGM45)
or 1x PCIe x 16 (for configuration with KTQM77)
4 Slide bracket with fixing screws
5 Air exhaust openings
6 Fans of the PSU (AC)
7 AC-power plug
8 Grounding stud
9 2x serial interfaces (RS232); only available in
configuration with KTQM77
7.2.1. Interfaces of the Motherboard on the Rear Side
Information and technical data can be found in the corresponding motherboard manual. You can
download the relevant motherboard manual for your system configuration from our web site at
7.2.2. Power Supply Unit
The power supply unit (PSU) is placed on the rear side of the KISS 1U Short platform (Fig. 10 and Fig. 11, pos. 6).
For information about the integrated power supply unit (PSU) and the rated voltage of your system, refer to the type label
attached on the right side of the unit.
