Operating Instructions Chassis Monitoring Module (CP3-CMM1)
31.01.2003 9
♦ Activation/deactivation of temperature sensor
inputs
Connected temperature sensors need to be
configured manually. All 7 temperature sensor
inputs are activated by default. If there are less
than 7 temperature sensors connected to the
CMM, the unconnected inputs need to be
deactivated. Otherwise, a “Temp Fail” Alarm will
be generated since the CMM detects a broken
sensor wire.
X = 0: Temperature sensor input deactivated
X = 1: Temperature sensor input activated
Address 14
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
fix 0
NTC1 x
NTC2 x
NTC3 x
NTC4 x
NTC5 x
NTC6 x
NTC7 x
Sum: 0 x x x x x x x
Default:
(Decimal 127) 0 1 1 1 1 1 1 1
♦ Selection of the parameters and Alarm
messages which are output via RS232
The parameters of the CMM like temperatures,
voltages and fan speed can be sent via RS232 to
the Hyperterminal. The following tables describe the
activation/deactivation of the RS232 output
parameters
Example of an output block, which is sent in a 2
second interval to the RS232:
HA: 22
T1:24 T2:24 T3:27 T4:23 T5:24 T6:29 T7:23 T8:23
T9:28
U1:3244 U2:4944 U3:11921 U5:-12050
S1:61
ERROR -- > OUT6
ERROR -- > OUT8
ERROR -- > OUT9
HA: PICMG 2.16 Hardware Address. Condition of
digital inputs DIN9...DIN13 (as decimal figure)
T1...T7: temperature of NTC 1...7 (in °C)
T8:
max. temperature of NTC 1...7 of CMM(in °C)
T9: max. temperature of NTC 1...4 of FCM (in °C)
U1...U6: system voltages +3.3V, +5V, +12V, +24V, -
12V, -24V (in mV)
S1: average fan speed (in %)
ERROR: Alarm message of a digital output
Output parameter
X = 0: Output of the parameter
X = 1: No output of the parameter
Address 47
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
fix
HA
x
T1 x
T2 x
T3 x
T4 x
T5 x
T5 x
T7 x
Sum: x x x x x x x x
Default:
(Decimal 255) 1 1 1 1 1 1 1 1
Address 48
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
fix
T8
x
T9 x
V1, +3.3V x
V2, +5V x
V3, +12V x
V4, +24V x
V5, -12V x
V6, -24V x
Sum: x x x x x x x x
Default:
(Decimal 255) 1 1 1 1 1 1 1 1
Address 49
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
fix 0 0 0 0 0 0
Fan speed
(S1) x
Output
globally on/off x
Sum: x 0 0 0 0 0 0 x
Default:
(Default 127) 1 0 0 0 0 0 0 1
