12 Appendix D: ETX® Connector Pinouts
Kontron User's Guide ETX®-LX
56
12.5
Connector X3 (VGA, LVDS, TTL, COM1 and COM2, LPT/Floppy, Mouse,
Keyboard)
12.5.1 Flat-Panel Interfaces
ETX®-LX modules can implement an LVDS flat-panel interface called JUMPtec
Intelligent LVDS Interface
(JILI). These modules implement optional a parallel digital flat-panel interface called JUMPtec
Intelligent Digital Interface (JIDI).
LVDS Interface Pinout (JILI)
Pin
Signal
Pin
Signal
1
GND
2
GND
3
R
4
B
5
HSY
6
G
7
VSY
8
DDCK
9
n.c.
10
DDDA
11
n.c.
12
TXCLK
13
n.c.
14
TXIN26_EN
15
GND
16
GND
17
n.c.
18
n.c.
19
n.c.
20
n.c.
21
GND
22
GND
23
LCDDO8
24
n.c.
25
LCDDO9
26
n.c.
27
GND
28
GND
29
LCDDO4
30
LCDDO7
31
LCDDO5
32
LCDDO6
33
GND
34
GND
35
LCDDO1
36
LCDDO3
37
LCDDO0
38
LCDDO2
39
VCC *
40
VCC *
41
JILI_DAT
42
LTGIO0
43
JILI_CLK
44
BLON#
45
BIASON
46
DIGON
47
COMP
48
Y
49
SYNC
50
C
Notes: To protect external power lines of peripheral devices, make sure that:
the wires have the right diameter to withstand the maximum available current
the enclosure of the peripheral device fulfils the fire-protection requirements of IEC/EN60950.
