11 Appendix C: BIOS Operation
Kontron User's Guide ETX®-LX 46
11.10 PnP/PCI Configurations
Feature Option Description
PNP OS Installed
No
Yes Select Yes if you are using a Plug and Play capable operating system.
Select No if you need the BIOS to configure non-Boot devices.
Init Display First
PCI/ISA Slot
Onboard This item allows you to decide whether to first activate the PCI slot or on-
chip VGA
Resources Controlled
By Auto
Manual
This item allows you to automatically configure all the boot- and Plug and
Play-compatible devices. If you select Auto, all the interrupt request (IRQ)
and DMA assignment fields are cleared, as the BIOS automatically assigns
them
IRQ Resources
Memory Resources
Submenu
When you are controlling resources manually, assign each system
interrupt a type, depending on the type of device (PCI or ISA) using the
interrupt.
Options (IRQ´s) - PCI device, Reserved (for ISA-Devices)
Options (Memory)- N/A, C800, CC00, D000, D400, D800 or DC00.
INT Pin 1-4 Assignment
Auto
3
4
5
7
9
10
11
12
14
15
Choose manually an Interrupt for PCI-Slot 1-4
