3 Specifications
Kontron User's Guide ETX®-LX 14
3.4.4 Supply Current
Power-consumption tests were executed under DOS and WindowsXP with 512MB of RAM.
DOS:
CPU Clock 500MHz
Mode Prompt Standby Suspend
Power
Consumption
1.48 A
7,38 W
1,28 A
6,43 W
1,28 A
6,43 W
Windows XP:
CPU Clock 500MHz
Mode Full Load Idle Standby S1 Standby S3
Power
Consumption
1.52 A
7,58 W
1,26 A
6,50 W
0,96 A
5,00 W 0,35 W
3.4.5 CMOS Battery Power Consumption
RTC Voltage Current
Winbond W83627HF
2.5V 1.6 µA
3.0V 2.7 µA
CMOS battery power consumption was measured with an ETX®-LX module on a standard Kontron ETX®
evaluation board. The system was turned off and the battery was removed from the evaluation board.
The 2.5 V or 3.0 V of power was supplied from a DC power supply. Do not use these values to calculate the
CMOS battery lifetime.
