SMARC-sAMX6i / Product Specification
3 Product Specification
3.1 SMARC-sAMX6i Feature Set
SMARC™ Feature specification SMARC™ Specification Maximum
Number Possible SMARC-sAMX6i Feature support SMARC-sAMX6i Featuresupport
instances
LVDS Display support 1 Yes 1
Parallel LCD support 1 Yes 1(24bit)
HDMI Display support 1 Yes 1
CSI Camera support (Dual and Quad
lanes) 2 Yes 1 (Quad lane)
Parallel Camera support 2 Yes 1
USB Interface 3 Yes 3
PCIe Interface 3 Yes 1 (3 PCIe lanes can be realised opionally)
SATA Interface 1 Yes 1 (0 on module with i.MX6 solo)
GbE Interface 1 Yes 1
SDIO Interface (4bit) 1 Yes 1 (max. 25MHz)
SDMMC Interface (8bit) 1 Yes 1 (max. 25MHz)
SPI Interface 2 Yes 2
I2S Interface 3 Yes 1
I2C Interface 5 Yes 5
CAN 2 Yes 2
AFB 1 Yes MLB150 is realised
I/O Voltage (1.8V) level support - Yes -
I/O Voltage (3.3V) level support - No -
8
