SMARC-sAMX6i / Connectors
P132 SER0_CTS# In W-PU CMOS / VDD_IO iMX6 EIM_D20 UART1_RTS_
B UART1_RTS_B ALT4 / ALT4 V_VIO_S0
P133 GND - - - - - - - - -
P134 SER1_TX Out - CMOS / VDD_IO iMX6 EIM_D26 UART2_TX_D
ATA
UART2_TX_DATA ALT4 / ALT4 V_VIO_S0
P135 SER1_RX In W-PU CMOS / VDD_IO iMX6 EIM_D27 UART2_RX_D
ATA UART2_RX_DATA ALT4 / ALT4 V_VIO_S0
P136 SER2_TX Out - CMOS / VDD_IO iMX6 CSI0_DAT1
2
UART4_TX_D
ATA
UART4_TX_DATA ALT3 / ALT3 V_VIO_S0
P137 SER2_RX In W-PU CMOS / VDD_IO iMX6 CSI0_DAT1
3 UART4_RX_D
ATA UART4_RX_DATA ALT3 / ALT3 V_VIO_S0
P138 SER2_RTS# Out - CMOS / VDD_IO iMX6 CSI0_DAT1
7
UART4_CTS_
B
UART4_CTS_B ALT3 / ALT3 V_VIO_S0
P139 SER2_CTS# In W-PU CMOS / VDD_IO iMX6 CSI0_DAT1
6 UART4_RTS_
B UART4_RTS_B ALT3 / ALT3 V_VIO_S0
P140 SER3_TX Out - CMOS / VDD_IO iMX6 CSI0_DAT1
4
UART5_TX_D
ATA
UART5_TX_DATA ALT3 / ALT3 V_VIO_S0
P141 SER3_RX In W-PU CMOS / VDD_IO iMX6 CSI0_DAT1
5 UART5_RX_D
ATA UART5_RX_DATA ALT3 / ALT3 V_VIO_S0
P142 GND - - - - - - - - -
P143 CAN0_TX Out - CMOS / VDD_IO iMX6 GPIO_7 FLEXCAN1_T
X
FLEXCAN1_TX ALT3 / ALT3 V_VIO_S0
P144 CAN0_RX In W-PU CMOS / VDD_IO iMX6 GPIO_8 FLEXCAN1_R
X FLEXCAN1_RX ALT3 / ALT3 V_VIO_S0
P145 CAN1_TX Out - CMOS / VDD_IO iMX6 KEY_COL4 FLEXCAN2_T
X
FLEXCAN2_TX ALT0 / ALT0 V_VIO_S0
P146 CAN1_RX In W-PU CMOS / VDD_IO iMX6 KEY_ROW4 FLEXCAN2_R
X
FLEXCAN2_RX ALT0 / ALT0 V_VIO_S0
P147 VDD_IN PWR - - - - - - - 3.0V-5.25V
P148 VDD_IN PWR - - - - - - - 3.0V-5.25V
P149 VDD_IN PWR - - - - - - - 3.0V-5.25V
P150 VDD_IN PWR - - - - - - - 3.0V-5.25V
P151 VDD_IN PWR - - - - - - - 3.0V-5.25V
P152 VDD_IN PWR - - - - - - - 3.0V-5.25V
P153 VDD_IN PWR - - - - - - - 3.0V-5.25V
P154 VDD_IN PWR - - - - - - - 3.0V-5.25V
P155 VDD_IN PWR - - - - - - - 3.0V-5.25V
P156 VDD_IN PWR - - - - - - - 3.0V-5.25V
