SMARC-sAMX6i / Connectors
4 _DATA04 A04
S98 LCD_D5 Out - CMOS / VDD_IO iMX6 DISP0_DAT
5 IPU1_DISP0
_DATA05 IPU1_DISP0_DAT
A05 ALT0 / ALT0 V_VIO_S0
S99 LCD_D6 Out - CMOS / VDD_IO iMX6 DISP0_DAT
6
IPU1_DISP0
_DATA06
IPU1_DISP0_DAT
A06
ALT0 / ALT0 V_VIO_S0
S100 LCD_D7 Out - CMOS / VDD_IO iMX6 DISP0_DAT
7 IPU1_DISP0
_DATA07 IPU1_DISP0_DAT
A07 ALT0 / ALT0 V_VIO_S0
S101 GND - - - - - - - - -
S102 LCD_D8 Out - CMOS / VDD_IO iMX6 DISP0_DAT
8
IPU1_DISP0
_DATA08
IPU1_DISP0_DAT
A08
ALT0 / ALT0 V_VIO_S0
S103 LCD_D9 Out - CMOS / VDD_IO iMX6 DISP0_DAT
9 IPU1_DISP0
_DATA09 IPU1_DISP0_DAT
A09 ALT0 / ALT0 V_VIO_S0
S104 LCD_D10 Out - CMOS / VDD_IO iMX6 DISP0_DAT
10
IPU1_DISP0
_DATA10
IPU1_DISP0_DAT
A10
ALT0 / ALT0 V_VIO_S0
S105 LCD_D11 Out - CMOS / VDD_IO iMX6 DISP0_DAT
11 IPU1_DISP0
_DATA11 IPU1_DISP0_DAT
A11 ALT0 / ALT0 V_VIO_S0
S106 LCD_D12 Out - CMOS / VDD_IO iMX6 DISP0_DAT
12
IPU1_DISP0
_DATA12
IPU1_DISP0_DAT
A12
ALT0 / ALT0 V_VIO_S0
S107 LCD_D13 Out - CMOS / VDD_IO iMX6 DISP0_DAT
13 IPU1_DISP0
_DATA13 IPU1_DISP0_DAT
A13 ALT0 / ALT0 V_VIO_S0
S108 LCD_D14 Out - CMOS / VDD_IO iMX6 DISP0_DAT
14
IPU1_DISP0
_DATA14
IPU1_DISP0_DAT
A14
ALT0 / ALT0 V_VIO_S0
S109 LCD_D15 Out - CMOS / VDD_IO iMX6 DISP0_DAT
15 IPU1_DISP0
_DATA15 IPU1_DISP0_DAT
A15 ALT0 / ALT0 V_VIO_S0
S110 GND - - - - - - - - -
S111 LCD_D16 Out - CMOS / VDD_IO iMX6 DISP0_DAT
16
IPU1_DISP0
_DATA16
IPU1_DISP0_DAT
A16
ALT0 / ALT0 V_VIO_S0
S112 LCD_D17 Out - CMOS / VDD_IO iMX6 DISP0_DAT
17 IPU1_DISP0
_DATA17 IPU1_DISP0_DAT
A17 ALT0 / ALT0 V_VIO_S0
S113 LCD_D18 Out - CMOS / VDD_IO iMX6 DISP0_DAT
18
IPU1_DISP0
_DATA18
IPU1_DISP0_DAT
A18
ALT0 / ALT0 V_VIO_S0
S114 LCD_D19 Out - CMOS / VDD_IO iMX6 DISP0_DAT
19 IPU1_DISP0
_DATA19 IPU1_DISP0_DAT
A19 ALT0 / ALT0 V_VIO_S0
S115 LCD_D20 Out - CMOS / VDD_IO iMX6 DISP0_DAT
20
IPU1_DISP0
_DATA20
IPU1_DISP0_DAT
A20
ALT0 / ALT0 V_VIO_S0
S116 LCD_D21 Out - CMOS / VDD_IO iMX6 DISP0_DAT
21 IPU1_DISP0
_DATA21 IPU1_DISP0_DAT
A21 ALT0 / ALT0 V_VIO_S0
S117 LCD_D22 Out - CMOS / VDD_IO iMX6 DISP0_DAT
22
IPU1_DISP0
_DATA22
IPU1_DISP0_DAT
A22
ALT0 / ALT0 V_VIO_S0
S118 LCD_D23 Out - CMOS / VDD_IO iMX6 DISP0_DAT
23 IPU1_DISP0
_DATA23 IPU1_DISP0_DAT
A23 ALT0 / ALT0 V_VIO_S0
S119 GND - - - - - - - - -
S120 LCD_DE Out PD-10k CMOS / VDD_IO iMX6 DI0_PIN15 IPU1_DI0_PI
N15
IPU1_DI0_PIN15 ALT0 / ALT0 V_VIO_S0
S121 LCD_VS Out - CMOS / VDD_IO iMX6 DI0_PIN3 IPU1_DI0_PI
N03 IPU1_DI0_PIN03 ALT0 / ALT0 V_VIO_S0
S122 LCD_HS Out - CMOS / VDD_IO iMX6 DI0_PIN2 IPU1_DI0_PI
N02
IPU1_DI0_PIN02 ALT0 / ALT0 V_VIO_S0
S123 LCD_PCK Out - CMOS / VDD_IO iMX6 DI0_DISP_
CLK IPU1_DI0_D
ISP_CLK IPU1_DI0_DISP_
CLK ALT0 / ALT0 V_VIO_S0
S124 GND - - - - - - - - -
S125 LVDS0+ Out - LVDS LCD iMX6 LVDS_TX0_
+
- - - V_NVCC_LV
DS2P5
S126 LVDS0- Out - LVDS LCD iMX6 LVDS_TX0_
- - - - V_NVCC_LV
DS2P5
S127 LCD_BKLT_EN Out - CMOS / VDD_IO iMX6 SD1_DAT0 GPIO1_IO16 GPIO1_IO16 ALT5 / ALT5 V_VIO_S0
S128 LVDS1+ Out - LVDS LCD iMX6 LVDS0_TX1
_+
- - - V_NVCC_LV
DS2P5
S129 LVDS1- Out - LVDS LCD iMX6 LVDS0_TX1
_- - - - V_NVCC_LV
DS2P5
S130 GND - - - - - - - - -
S131 LVDS2+ Out - LVDS LCD iMX6 LVDS0_TX2
_+
- - - V_NVCC_LV
DS2P5
S132 LVDS2- Out - LVDS LCD iMX6 LVDS0_TX2
_- - - - V_NVCC_LV
DS2P5
S133 LCD_VDD_EN Out - CMOS / VDD_IO iMX6 SD1_DAT1 GPIO1_IO17 GPIO1_IO17 ALT5 / ALT5 V_VIO_S0
S134 LVDS_CK+ Out - LVDS LCD iMX6 LVDS0_CLK
_+
- - - V_NVCC_LV
DS2P5
S135 LVDS_CK- Out - LVDS LCD iMX6 LVDS0_CLK
_- - - - V_NVCC_LV
DS2P5
S136 GND - - - - - - - - -
S137 LVDS3+ Out - LVDS LCD iMX6 LVDS0_TX3
_+
- - - V_NVCC_LV
DS2P5
S138 LVDS3- Out - LVDS LCD iMX6 LVDS0_TX3
_- - - - V_NVCC_LV
DS2P5
S139 I2C_LCD_CK Out PU-2k2 CMOS / VDD_IO iMX6 SD1_DAT2 GPIO1_IO19 GPIO1_IO19 ALT5 / ALT5 V_VIO_S0
S140 I2C_LCD_DAT Bi-Dir PU-2k2 CMOS / VDD_IO iMX6 SD1_DAT3 GPIO1_IO21 GPIO1_IO21 ALT5 / ALT5 V_VIO_S0
