SMARC-sAMX6i / Connectors
S47 GND - - - - - - - - -
S48 I2C_GP_CK Out PU-2k2 CMOS / VDD_IO iMX6 CSI0_DAT9 I2C1_SCL I2C1_SCL ALT4 / ALT4 V_VIO_S0
S49 I2C_GP_DAT Bi-Dir PU-2k2 CMOS / VDD_IO iMX6 CSI0_DAT8 I2C1_SDA I2C1_SDA ALT4 / ALT4 V_VIO_S0
S50 I2S2_LRCK Bi-Dir - CMOS / VDD_IO iMX6 DISP0_DAT
18 AUD5_TXFS AUD5_TXFS ALT3 / ALT3 V_VIO_S0
S51 I2S2_SDOUT Out - CMOS / VDD_IO iMX6 DISP0_DAT
17
AUD5_TXD AUD5_TXD ALT3 / ALT3 V_VIO_S0
S52 I2S2_SDIN In - CMOS / VDD_IO iMX6 DISP0_DAT
19 AUD5_RXD AUD5_RXD ALT3 / ALT3 V_VIO_S0
S53 I2S2_CK Bi-Dir - CMOS / VDD_IO iMX6 DISP0_DAT
16
AUD5_TXC AUD5_TXC ALT3 / ALT3 V_VIO_S0
S54 SATA_ACT# - - CMOS / VDD_IO - - - - - -
S55 AFB8_PTIO - - CMOS / VDD_IO - - - - - -
S56 AFB9_PTIO - - CMOS / VDD_IO - - - - - -
S57 PCAM_ON_CSI0# type float - - - - - - -
S58 PCAM_ON_CSI1# type GND - - - - - - -
S59 SPDIF_OUT Out PU-2k2 CMOS / VDD_IO iMX6 ENET_RXD0 SPDIF_OUT SPDIF_OUT ALT3 / ALT3 V_3V3_S0
S60 SPDIF_IN In PU-2k2 CMOS / VDD_IO iMX6 ENET_RX_E
R SPDIF_IN SPDIF_IN ALT3 / ALT3 V_3V3_S0
S61 GND - - - - - - - - -
S62 AFB_DIFF0+ Bi-Dir - LVDS_AFB - - - - - -
S63 AFB_DIFF0- Bi-Dir - LVDS_AFB - - - - - -
S64 GND - - - - - - - - -
S65 AFB_DIFF1+ Bi-Dir - LVDS_AFB - - - - - -
S66 AFB_DIFF1- Bi-Dir - LVDS_AFB - - - - - -
S67 GND - - - - - - - - -
S68 AFB_DIFF2+ Bi-Dir - LVDS_AFB iMX6 MLB_CP - - - -
S69 AFB_DIFF2- Bi-Dir - LVDS_AFB iMX6 MLB_CN - - - -
S70 GND - - - - - - - - -
S71 AFB_DIFF3+ Bi-Dir - LVDS_AFB iMX6 MLB_DP - - - -
S72 AFB_DIFF3- Bi-Dir - LVDS_AFB iMX6 MLB_DN - - - -
S73 GND - - - - - - - - -
S74 AFB_DIFF4+ Bi-Dir - LVDS_AFB iMX6 MLB_SP - - - -
S75 AFB_DIFF4- Bi-Dir - LVDS_AFB iMX6 MLB_SN - - - -
- - - - - - - - - -
S76 PCIE_B_RST# Out - CMOS 3.3V CPLD - - - - V_3V3_S5
- - - - - iMX6 EIM_DA14 GPIO3_IO14 GPIO3_IO14 ALT5 / ALT5 V_VIO_S0
S77 PCIE_C_RST# Out - CMOS 3.3V CPLD - - - - V_3V3_S5
- - - - - iMX6 EIM_DA15 GPIO3_IO15 GPIO3_IO15 ALT5 / ALT5 V_VIO_S0
S78 PCIE_C_RX+ In - LVDS PCIe PEX8605 PEX_PET+[
3]
- - - PEX_VDDA
S79 PCIE_C_RX- In - LVDS PCIe PEX8605 PEX_PET-
[3] - - - PEX_VDDA
S80 GND - - - - - - - - -
S81 PCIE_C_TX+ Out Seriell-100n LVDS PCIe PEX8605 PEX_PET+[
3]
- - - PEX_VDDA
S82 PCIE_C_TX- Out Seriell-100n LVDS PCIe PEX8605 PEX_PET-
[3] - - - PEX_VDDA
S83 GND - - - - - - - - -
S84 PCIE_B_REFCK+ Out - LVDS PCIe PEX8605 PEX_REFCL
K_OUT+2
- - - PEX_VDDA
S85 PCIE_B_REFCK- Out - LVDS PCIe PEX8605 PEX_REFCL
K_OUT-2 - - - PEX_VDDA
S86 GND - - - - - - - - -
S87 PCIE_B_RX+ In - LVDS PCIe PEX8605 PEX_PER+[
2]
- - - PEX_VDDA
S88 PCIE_B_RX- In - LVDS PCIe PEX8605 PEX_PER-
[2] - - - PEX_VDDA
S89 GND - - - - - - - - -
S90 PCIE_B_TX+ Out Seriell-100n LVDS PCIe PEX8605 PEX_PET+[
2]
- - - PEX_VDDA
S91 PCIE_B_TX- Out Seriell-100n LVDS PCIe PEX8605 PEX_PET-
[2] - - - PEX_VDDA
S92 GND - - - - - - - - -
S93 LCD_D0 Out - CMOS / VDD_IO iMX6 DISP0_DAT
0
IPU1_DISP0
_DATA00
IPU1_DISP0_DAT
A00
ALT0 / ALT0 V_VIO_S0
S94 LCD_D1 Out - CMOS / VDD_IO iMX6 DISP0_DAT
1 IPU1_DISP0
_DATA01 IPU1_DISP0_DAT
A01 ALT0 / ALT0 V_VIO_S0
S95 LCD_D2 Out - CMOS / VDD_IO iMX6 DISP0_DAT
2
IPU1_DISP0
_DATA02
IPU1_DISP0_DAT
A02
ALT0 / ALT0 V_VIO_S0
S96 LCD_D3 Out - CMOS / VDD_IO iMX6 DISP0_DAT
3 IPU1_DISP0
_DATA03 IPU1_DISP0_DAT
A03 ALT0 / ALT0 V_VIO_S0
S97 LCD_D4 Out - CMOS / VDD_IO iMX6 DISP0_DAT IPU1_DISP0 IPU1_DISP0_DAT ALT0 / ALT0 V_VIO_S0
27
