COMe-cCT6 / Pinout List
7.4
Connector X1B Row C
Pin
Signal
Description
Type
Termination Comment
C1
GND
Power Ground
PWR
-
-
C2
GND
Power Ground
PWR
-
-
C3
USB_SSRX0-
USB Super Speed Receive - (0) DP-I
-
-
C4
USB_SSRX0+
USB Super Speed Receive + (0) DP-I
-
-
C5
GND
Power Ground
PWR
-
-
C6
USB_SSRX1-
USB Super Speed Receive - (1) DP-I
-
-
C7
USB_SSRX1+
USB Super Speed Receive + (1) DP-I
-
-
C8
GND
Power Ground
PWR
-
-
C9
USB_SSRX2-
Not Connected
nc
-
-
C10
USB_SSRX2+
Not Connected
nc
-
-
C11
GND
Power Ground
PWR
-
-
C12
USB_SSRX3-
Not Connected
nc
-
-
C13
USB_SSRX3+
Not Connected
nc
-
-
C14
GND
Power Ground
PWR
-
-
C15
DDI1_PAIR6+
Not Connected
nc
-
-
C16
DDI1_PAIR6-
Not Connected
nc
-
-
C17
RSVD
Not Connected
nc
-
-
C18
RSVD
Not Connected
nc
-
-
C19
PCIE_RX6+
Not Connected
nc
-
-
C20
PCIE_RX6-
Not Connected
nc
-
-
C21
GND
Power Ground
PWR
-
-
C22
PCIE_RX7+
Not Connected
nc
-
-
C23
PCIE_RX7-
Not Connected
nc
-
-
C24
DDI1_HPD
DDI1 Hotplug Detect
I-3,3
PD 1M
-
C25
DDI1_PAIR4+
Not Connected
nc
-
-
C26
DDI1_PAIR4-
Not Connected
nc
-
-
C27
RSVD
Not Connected
nc
-
-
C28
RSVD
Not Connected
nc
-
-
C29
DDI1_PAIR5+
Not Connected
nc
-
-
C30
DDI1_PAIR5-
Not Connected
nc
-
-
C31
GND
Power Ground
PWR
-
-
C32
DDI2_CTRLCLK_AUX+
DDI2 CTRLCLK/AUX+
I/O-3,3 -
-
C33
DDI2_CTRLDATA_AUX- DDI2 CTRLDATA/AUX-
I/O-3,3 -
-
C34
DDI2_DDC_AUX_SEL
DDI2 DDC/AUX select
I-3,3
PD 1M
-
C35
RSVD
n.c.
nc
-
-
C36
DDI3_CTRLCLK_AUX+
Not Connected
nc
-
-
C37
DDI3_CTRLDATA_AUX- Not Connected
nc
-
-
C38
DDI3_DDC_AUX_SEL
Not Connected
nc
-
-
C39
DDI3_PAIR0+
Not Connected
nc
-
-
C40
DDI3_PAIR0-
Not Connected
nc
-
-
C41
GND
Power Ground
PWR
-
-
C42
DDI3_PAIR1+
Not Connected
nc
-
-
C43
DDI3_PAIR1-
Not Connected
nc
-
-
C44
DDI3_HPD
Not Connected
nc
-
-
C45
RSVD
Not Connected
nc
-
-
C46
DDI3_PAIR2+
Not Connected
nc
-
-
C47
DDI3_PAIR2-
Not Connected
nc
-
-
C48
RSVD
Not Connected
nc
-
-
C49
DDI3_PAIR3+
Not Connected
nc
-
-
C50
DDI3_PAIR3-
Not Connected
nc
-
-
C51
GND
Power Ground
PWR
-
-
C52
PEG_RX0+
Not Connected
nc
-
-
C53
PEG_RX0-
Not Connected
nc
-
-
C54
TYPE0#
n.c. for type 6 module
nc
-
-
C55
PEG_RX1+
Not Connected
nc
-
-
C56
PEG_RX1-
Not Connected
nc
-
-
C57
TYPE1#
n.c. for type 6 module
nc
-
-
C58
PEG_RX2+
Not Connected
nc
-
-
C59
PEG_RX2-
Not Connected
nc
-
-
C60
GND
Power Ground
PWR
-
-
C61
PEG_RX3+
Not Connected
nc
-
-
C62
PEG_RX3-
Not Connected
nc
-
-
C63
RSVD
Not Connected
nc
-
-
C64
RSVD
Not Connected
nc
-
-
