COMe-cCT6 / Product Specification
3 Product Specification
3.1 Modules definition
The COM Express® compact sized Computer-on-Module COMe-cCT6 (UUP6) follows pin-out Type 6 and is compatible to
PICMG specification COM.0 Rev 2.1. The COMe-cCT6, based on Intel's Cedar Trail platform, is available in different variants
to cover the demand of different performance, price and power:
Commercial grade modules (0°C to 60°C operating)
Product Number Product Name Processor UART Flash USB 3.0 TPM
36011-0040-19-7 COMe-cCT6 D2550 Cedarview-D Intel® Atom™ D2550 2x 4GB SLC 2x Yes
36011-0000-19-6 COMe-cCT6 D2550 Cedarview-D Intel® Atom™ D2550 - - - -
36011-0000-19-2 COMe-cCT6 N2800 Cedarview-M Intel® Atom™ N2800 - - - -
36011-0000-16-3 COMe-cCT6 N2600 SER Cedarview-M Intel® Atom™ N2600 2x - - -
36011-0000-16-2 COMe-cCT6 N2600 Cedarview-M Intel® Atom™ N2600 - - - -
Optional hardware features:
» TPM
» PCI Express USB 3.0 (xHCI) controller TI
» 2x UART
» 2 to 32GB SLC NANDrive
» 2 to 64GB MLC NANDrive
Optional BIOS features:
» Secure Flash Update
» Secure Boot
» CSM OptOut
Extended temperature grade modules (E1, -25°C to 75°C operating)
Product Number Product Name Processor UART Flash USB 3.0 TPM
36011-0000-19-6EXT COMe-cCT6 D2550 E1 Cedarview-D Intel® Atom™ D2550 - - - -
36011-0000-19-2EXT COMe-cCT6 N2800 E1 Cedarview-M Intel® Atom™ N2800 - - - -
36011-0000-16-2EXT COMe-cCT6 N2600 E1 Cedarview-M Intel® Atom™ N2600 - - - -
Optional hardware features:
» PCI Express USB 3.0 (xHCI) controller TI
» 2x UART
» 2 to 32GB SLC NANDrive
» 2 to 64GB MLC NANDrive (industrial grade versions only)
Industrial temperature grade modules (XT, -40°C to 85°C operating)
Modules for E2 temperature range are available by screening on project base, please contact your local sales or support
for further details.
Part Number Product Name Processor UART Flash USB 3.0 TPM
36011-00FF-CC-x COMe-cCT6 XT All optional optional n/a n/a
Optional hardware and BIOS features are available project based only for variants not listed
above. Please contact your local sales for customized articles.
