COMe-cCT6 / Features and Interfaces
4.15 Display Configuration
The chapter describes possible display configurations and supported features for the integrated Intel® GMA 3650 / 3600
graphics.
Dual Display Configurations in O/S
Display N/A CRT LVDS fix LVDS DID LVDS2DVI DP DP2DVI DP2HDMI DP2CRT
N/A - S S S S S S S S
CRT S - A A A A A A A
LVDS fix S A - - - A A A A
LVDS DID S A - - - A A A A
LVDS2DVI S A - - - A A A A
DP S A A A A A A A A
DP2DVI S A A A A A A A A
DP2HDMI S A A A A A A A A
DP2CRT S A A A A A A A A
eDP - - - - - - - - -
» S = Single Display
» A = All Modes (Single Display, Clone Mode, Extended Desktop)
» A* = All Modes, but requires a customized BIOS
» - = Not supported
» N/A = Display not attached
