COMe-cCT6 / Features and Interfaces

Dual Display configurations in Setup and POST

Display

N/A

CRT

LVDS fix

LVDS DID

LVDS2DVI

DP

DP2DVI

DP2HDMI

DP2CRT

N/A

-

S

S

S

S

S

S

S

S

CRT

S

-

C

C*

Twin

C

C

C

C

LVDS fix

S

C

-

-

-

C

C

C

C

LVDS DID

S

C*

-

-

-

C*

C*

C*

C*

LVDS2DVI

S

Twin

-

-

-

C

C

C

C

DP

S

C

C

C*

C

C

C

C

C

DP2DVI

S

C

C

C*

C

C

C

C

C

DP2HDMI

S

C

C

C*

C

C

C

C

C

DP2CRT

S

C

C

C*

C

C

C

C

C

eDP

-

-

-

-

-

-

-

-

-

» S = Single Display

» C = Clone Mode

» C* = Clone Mode, requires manual display configuration in setup. With Auto detection LVDS only is supported

» Twin = Twin Mode with 2 Displays on Display Pipe 1.

» - = Not supported

» N/A = Display not attached

In Clone Mode Display Pipe 2 only shows VESA Modes in POST, Setup and EFI Shell. DOS,
Windows boot or the Windows Installation is using VGA Mode which is not supported by
Display Pipe 2. With CRT and LVDS with EDID (e.g. LVDS2DVI Adapter) the Twin Mode is
active without VESA mode restrictions

45
