3.13.1 FAN
The COMe-cCT6 supports an onboard FAN connector for active cooling controlled by the BIOS.
Specification of the FAN Connector:
» Part number (Molex): 53261-0371
» Mates with: 51021-0300
» Crimp terminals: 50079-8100
Pin assignment
» Pin1: Tacho, Pin2: VCC, Pin3: GND
Electrical characteristic
Module Input Voltage
4.75 - 13V
>13V
FAN Output Voltage
4.75 - 13V
13V
Max. FAN Output Current
350mA
150mA
To connect a standard FAN with 3pin connector to the module please use adaptor cable
KAB-HSP 200mm (96079-0000-00-0) or KAB-HSP 40mm (96079-0000-00-2)
3.13.2 CPU Debug & CPLD
The CPU Debug connector J4 (not soldered by default) and the CPLD programming interface J7 are for internal use only
and should not be used.
