Page 55
COMe-cCT6 / Pinout List
7.2
Connector X1A Row A
Pin
Signal
Description
Type
Termination
Comment
A1
GND_1
Power Ground
PWR
-
-
A2
GBE0_MDI3-
Ethernet Receive Data-
DP-I
-
-
A3
GBE0_MDI3+
Ethernet Receive Data+
DP-I
-
-
A4
GBE0_LINK100#
Ethernet Speed LED 100Mbps
OD
-
-
A5
GBE0_LINK1000# Ethernet Speed LED 1000Mbps
OD
-
-
A6
GBE0_MDI2-
Ethernet Receive Data-
DP-I
-
-
A7
GBE0_MDI2+
Ethernet Receive Data+
DP-I
-
-
A8
GBE0_LINK#
LAN Link LED
OD
-
-
A9
GBE0_MDI1-
Ethernet Receive Data-
DP-I
-
-
A10
GBE0_MDI1+
Ethernet Receive Data+
DP-I
-
-
A11
GND_2
Power Ground
PWR
-
-
A12
GBE0_MDI0-
Ethernet Transmit Data-
DP-O
-
-
A13
GBE0_MDI0+
Ethernet Transmit Data+
DP-O
-
-
A14
GBE0_CTREF
LAN Reference Voltage
O-3.3
100nF to GND
-
A15
SUS_S3#
Indicates Suspend to RAM state
O-3.3
-
CPLD I/O
A16
SATA0_TX+
SATA 0 Transmit Data+
DP-O
-
-
A17
SATA0_TX-
SATA 0 Transmit Data-
DP-O
-
-
A18
SUS_S4#
Indicates Suspend to Disk state
O-3.3
-
-
A19
SATA0_RX+
SATA 0 Receive Data+
DP-I
-
-
A20
SATA0_RX-
SATA 0 Receive Data-
DP-I
-
-
A21
GND_3
Power Ground
PWR
-
-
A22
SATA2_TX+
Not Connected
nc
-
-
A23
SATA2_TX-
Not Connected
nc
-
-
A24
SUS_S5#
Indicates Soft Off state
O-3.3
-
CPLD I/O
A25
SATA2_RX+
Not Connected
nc
-
-
A26
SATA2_RX-
Not Connected
nc
-
-
A27
BATLOW#
Indicates low external battery
I-3.3
-
-
A28
ATA_ACT#
SATA Activity Indicator
OD
-
-
A29
HDA_SYNC
HD Audio SYNC
O-3.3
PD 20k in NM10
-
A30
HDA_RST#
HD Audio Reset
O-3.3
-
-
A31
GND_4
Power Ground
PWR
-
-
A32
HDA_CLK
HD Audio CLK
O-3.3
PD 20k in NM10
24MHz
A33
HDA_SDOUT
HD Audio Data
O-3.3
PD 20k in NM10
-
A34
BIOS_DIS0#
Disable Module BIOS.
I-3.3
PU 10k 3.3V_S5
-
A35
THRMTRIP#
CPU thermal shutdown indicator
O-3.3
PU 10k 3.3V_S0
-
A36
USB6-
USB Data- Port #6
DP-I/O
PD 15k in NM10
-
A37
USB6+
USB Data+ Port #6
DP-I/O
PD 15k in NM10
-
A38
USB_6_7_OC#
USB Over current Pair 6 / 7
I-3.3
PU 10k 3.3V_S5
-
A39
USB4-
USB Data- Port #4
DP-I/O
PD 15k in NM10
-
A40
USB4+
USB Data+ Port #4
DP-I/O
PD 15k in NM10
-
A41
GND_5
Power Ground
PWR
-
-
A42
USB2-
USB Data- Port #2
DP-I/O
PD 15k in NM10
-
A43
USB2+
USB Data+ Port #2
DP-I/O
PD 15k in NM10
-
A44
USB_2_3_OC#
USB Over current Pair 2 / 3
I-3.3
PU 10k 3.3V_S5
-
A45
USB0-
USB Data- Port #0
DP-I/O
PD 15k in NM10
-
A46
USB0+
USB Data+ Port #0
DP-I/O
PD 15k in NM10
-
A47
VCC_RTC
RTC Battery Supply +3V
PWR
-
-
A48
EXCD0_PERST#
PCI Express Card 0 Reset
O-3.3
-
-
A49
EXCD0_CPPE#
PCI Express Card 0 Request
I-3.3
PU 8k25 3.3V_S0
-
A50
LPC_SERIRQ
LPC Serial Interrupt Request
IO-3.3
PU 10k 3.3V_S0
-
A51
GND_6
Power Ground
PWR
-
-
A52
PCIE_TX5+
Not Connected
nc
-
-
A53
PCIE_TX5-
Not Connected
nc
-
-
A54
GPI0
General Purpose Input 0
I/O-3.3 PU 10k/100k to V3.3_S0 -
A55
PCIE_TX4+
Not Connected
nc
-
-
A56
PCIE_TX4-
Not Connected
nc
-
-
A57
GND_7
Power Ground
PWR
-
-
A58
PCIE_TX3+
PCIe lane #3 Transmit+ (Optional)
DP-O
-
only available on no-LAN var.
A59
PCIE_TX3-
PCIe lane #3 Transmit- (Optional)
DP-O
-
only available on no-LAN var.
A60
GND_8
Power Ground
PWR
-
-
A61
PCIE_TX2+
PCIe lane #2 Transmit+
DP-O
-
-
A62
PCIE_TX2-
PCIe lane #2 Transmit-
DP-O
-
-
A63
GPI1
General Purpose Input 1
I/O-3.3 PU 10k/100k to V3.3_S0 -
A64
PCIE_TX1+
PCIe lane #1 Transmit+
DP-O
-
-
