COMe-cCT6 / Pinout List
B65
PCIE_RX1-
PCIe lane #1 Receive-
DP-I
-
-
B66
WAKE0#
PCI Express Wake Event
I-3.3
PU 1k 3.3V_S5
-
B67
WAKE1#
General Purpose Wake Event
I-3.3
PU 10k 3.3V_S5
-
B68
PCIE_RX0+
PCIe lane #0 Receive+
DP-I
-
-
B69
PCIE_RX0-
PCIe lane #0 Receive-
DP-I
-
-
B70
GND_23
Power Ground
PWR
-
-
B71
LVDS_B0+
Not Connected
nc
-
-
B72
LVDS_B0-
Not Connected
nc
-
-
B73
LVDS_B1+
Not Connected
nc
-
-
B74
LVDS_B1-
Not Connected
nc
-
-
B75
LVDS_B2+
Not Connected
nc
-
-
B76
LVDS_B2-
Not Connected
nc
-
-
B77
LVDS_B3+
Not Connected
nc
-
-
B78
LVDS_B3-
Not Connected
nc
-
-
B79
LVDS_BKLT_EN
Backlight Enable
O-3.3
-
-
B80
GND_24
Power Ground
PWR
-
-
B81
LVDS_B_CK+
Not Connected
nc
-
-
B82
LVDS_B_CK-
Not Connected
nc
-
-
B83
LVDS_BKLT_CTRL Backlight Brightness Control
O-3.3
-
-
B84
VCC_5V_SBY
+5V Standby
PWR
-
-
B85
VCC_5V_SBY
+5V Standby
PWR
-
-
B86
VCC_5V_SBY
+5V Standby
PWR
-
-
B87
VCC_5V_SBY
+5V Standby
PWR
-
-
B88
BIOS_DIS1#
Disable Module BIOS.Enable boot from SPI on Baseboard I-3.3
PU 10k 3.3V_S5
For ext.SPI
B89
CRT_RED
CRT_RED / Analog Video RGB-RED
OA
PD 150R
-
B90
GND_25
Power Ground
PWR
-
-
B91
CRT_GREEN
CRT_GREEN / Analog Video RGB-GREEN
OA
PD 150R
-
B92
CRT_BLUE
CRT_BLUE / Analog Video RGB-BLUE
OA
PD 150R
-
B93
CRT_HSYNC
CRT_HSYNC / Analog Video H-Sync
O-3,3
-
-
B94
CRT_VSYNC
CRT_VSYNC / Analog Video V-Sync
O-3,3
-
-
B95
CRT_DDC_CLK
CRT_DDC_CLK / Display Data Channel Clock
I/O-5
PU 2k21 5.0V_S0
-
B96
CRT_DDC_DATA
CRT_DDC_DATA / Display Data Channel Data
I/O-5
PU 2k21 5.0V_S0
-
B97
SPI_CS#
SPI Chipselect
O
3.3V_S5
-
B98
RSVD
Not Connected
nc
-
-
B99
RSVD
Not Connected
nc
-
-
B100 GND_26
Power Ground
PWR
-
-
B101 FAN_PWMOUT
FAN PWM out
O-3.3
-
14.5V tolerance
B102 FAN_TACHIN
FAN Tacho in
I-3.3
PU 47k 3.3V_S0
14.5V tolerance
B103 SLEEP#
Sleep button
I-3.3
PU 47k 3.3V_S5
14.5V tolerance
B104 VCC_12V_16
12V VCC
PWR
-
-
B105 VCC_12V_17
12V VCC
PWR
-
-
B106 VCC_12V_18
12V VCC
PWR
-
-
B107 VCC_12V_19
12V VCC
PWR
-
-
B108 VCC_12V_20
12V VCC
PWR
-
-
B109 VCC_12V_21
12V VCC
PWR
-
-
B110 GND_27
Power Ground
PWR
-
-
