COMe-mSP1 / Features and Interfaces
VGA
The nanoETXexpress-SP graphics subsystem GMA500 integrated in the Intel® System Controller Hub US15W does not
support VGA output.
LVDS Flat Panel Interface (JILI)
The user interface for flat panels is the JUMPtec Intelligent LVDS Interface (JILI). The implementation of this subsystem
complies with the COM Express® Specification. Implementation information is provided in the COM Express® Design
Guide. Refer to the documentation for additional information.
SDVO
A Serial DVO connection is supported with hardware revision CE 4.x.x or newer. The digital display channel configured
from display Pipe A in GMA500 graphics adapter is capable of driving SDVO adapters that provide interfaces to a variety of
external display technologies such as HDMI, DVI, TV-out or CRT (the maximum supported pixel clock is 160MHz). Contact
your local sales representative which adapters are available.
SDVO is optional available via:
» 30pin onboard flat foil connector
» COM Express connector (recommended solution)
Alternative COM Express Pin-out with SDVO option:
Pin Standard Signal SDVO Option SDVO Option Pin Description Type SDVO Termination
B71 LVDS_B0+ SDVOB_RED_P Serial Digital Video Channel B Red+ DP-O PU 50R inUS15W
B72 LVDS_B0- SDVOB_RED_N Serial Digital Video Channel B Red- DP-O PU 50R inUS15W
B73 LVDS_B1+ SDVOB_GREEN_P Serial Digital Video Channel B Green+ DP-O PU 50R inUS15W
B74 LVDS_B1- SDVOB_GREEN_N Serial Digital Video Channel B Green- DP-O PU 50R inUS15W
B75 LVDS_B2+ SDVOB_BLUE_P Serial Digital Video Channel B Blue+ DP-O PU 50R inUS15W
B76 LVDS_B2- SDVOB_BLUE_N Serial Digital Video Channel B Blue- DP-O PU 50R inUS15W
B77 LVDS_B3+ SDVOB_INT_P Serial Digital Video Input Interrupt+ DP-I PD 50R inUS15W
B78 LVDS_B3- SDVOB_INT_N Serial Digital Video Input Interrupt- DP-I PD 50R inUS15W
.. .. .. .. .. ..
B81 LVDS_B_CK+ SDVOB_CLK_P Serial Digital Video Channel B Clock+ DP-O PU 50R inUS15W
B82 LVDS_B_CK- SDVOB_CLK_N Serial Digital Video Channel B Clock- DP-O PU 50R inUS15W
.. .. .. .. .. ..
B91 VGA_GRN SDVOB_TVCLKIN_P SDVO Channel B TV-Out Sync Clock+ DP-I PD 50R inUS15W
B92 VGA_BLU SDVOB_TVCLKIN_N SDVO Channel B TV-Out Sync Clock- DP-I PD 50R inUS15W
B93 VGA_HSYNC SDVOB_STALL_P Serial Digital Video Field Stall+ DP-I PD 50R inUS15W
B94 VGA_VSYNC SDVOB_STALL_N Serial Digital Video Field Stall- DP-I PD 50R inUS15W
B95 VGA_I2C_CK SDVO_CTRLCLK SDVO Control Clock DP-I/O ..
B96 VGA_I2C_DAT SDVO_CTRLDATA SDVO Control DATA DP-I/O ..
- The SDVO option is not available on standard modules. Please contact your local sales
representative for more details or further questions.
- The optional SDVO pinout is similar to Type 10 pin-out except SDVO Control CLK/DAT on
B95/B96 (B98/B99 on Type 10)
