COMe-mSP1 / Product Specification
3 Product Specification
3.1 Modules & Accessories
The COM Express® mini sized Computer-on-Module COMe-mSP1 (NOW1) follows pin-out Type 1 and is compatible to PICMG
specification COM.0 Rev 1.0. The COMe-mSP1, based on Intel's eMenlow platform, is available in different variants to
cover the demand of different performance, price and power:
Commercial grade modules (0°C to 60°C operating)
Product Number Product Name Processor SCH and Features
34001-2040-16-1 COMe-mSP1 Z530 2GB/4GB Intel® Atom™ Z530 US15W, 1xPCIe, 2GB DDR2, 4GB SSD
34001-1040-16-1 COMe-mSP1 Z530 1GB/4GB Intel® Atom™ Z530 US15W, 1xPCIe, 1GB DDR2, 4GB SSD
34001-5120-16-1 COMe-mSP1 Z530 512MB/2GB Intel® Atom™ Z530 US15W, 1xPCIe, 512MB DDR2, 2GB SSD
34001-1020-11-1 COMe-mSP1 Z510 1GB/2GB Intel® Atom™ Z510 US15W, 1xPCIe, 1GB DDR2, 2GB SSD
34001-5151-11-1 COMe-mSP1 Z530 512/512MB Intel® Atom™ Z510 US15W, 1xPCIe, 512MB DDR2, 512MB SSD
Extended temperature modules (E1, -25°C to 75°C operating)
Product Number Product Name Processor SCH and Features
34001-1040-16-1EXT COMe-mSP1 Z530 1GB/4GB E1 Intel® Atom™ Z530 US15W, 1xPCIe, LAN, 1GB DDR2, 4GB SSD
34001-5120-16-1EXT COMe-mSP1 Z530 512/2GB E1 Intel® Atom™ Z530 US15W, 1xPCIe, LAN, 512MB DDR2, 2GB SSD
34001-5151-11-1EXT COMe-mSP1 Z510 512/512M E1 Intel® Atom™ Z510 US15W, 1xPCIe, LAN, 512MB DDR2, 512MB SSD
Possible memory and onboard Flash configurations 34001-MMFF-xx-x:
» MM = 51: 512MB DDR2 Memory (4 x 1Gb chips on bottom)
» MM = 10: 1024MB DDR2 Memory (8 x 1Gb chips)
» MM = 20: 2048MB DDR2 Memory (8 x 2Gb chips)
» FF = 00: without PATA SSD
» FF = 51: 512MB onboard PATA SSD
» FF = 10: 1GB onboard PATA SSD
» FF = 20: 2GB onboard PATA SSD
» FF = 40: 4GB onboard PATA SSD
Please contact your local sales for customized Memory and Flash variants or modules with
2xPCIe (no-LAN version)
