COMe-mSP1 / Product Specification
Graphics Core
The integrated Intel® GMA 500 based on PowerVR SGX535 core supports:
Graphics Core Render Clock 200MHz, ,
Execution Units / Pixel Pipelines 4
Max Graphics Memory 352MB
GFX Memory Bandwidth (GB/s) 4.2
GFX Memory Technology DVMT
API (DirectX/OpenGL) 9.0c / 2.0
Shader Model 3.0
Hardware accelerated Video H.264,MPEG2/4,VC1,WMV9
Independent/Simultaneous Displays 2 (with SDVO option)
Display Port -
HDCP support -
Monitor output
CRT max Resolution -
TV out: -
LVDS
LVDS Bits/Pixel 1x18 / 1x24
LVDS Bits/Pixel with dithering -
LVDS max Resolution: 1366x768, 112MHz
PWM Backlight Control: YES
Supported Panel Data: JILI2/JILI3/EDID/DID
Display Interfaces
Discrete Graphics -
Digital Display Interface DDI1 SDVOB optional
Digital Display Interface DDI2 -
Digital Display Interface DDI3 -
Maximum Resolution on DDI 1600x1200
Chipset
The 130nm Intel System Controller Hub Poulsbo supports:
» PCI Express Revision 1.0
» USB 2.0
» USB Client
» SDIO 1.0
Storage
onboard SSD 512MB to 8GB SLC (PATA)
SD Card support SD 1.1 shared with GPIO
IDE Interface -
Serial-ATA 1x SATA 1.5GB/s
SATA AHCI -
SATA RAID -
When using a hard disk on SATA #0 as primary device for the operating system the boot
order should be changed according the usage. Wrong boot order may cause problems
writing the MBR during OS installation.
