IPMI Firmware User Guide: AM4010
POST Value OEM Post Value (C6h) /
OEM (78h) 0000h /
0000h /
00FFh
POST Value (from
host I/O port 80h) N
FWH0 Boot Err Boot Error (1Eh) / Sensor-
specific 0008h /
0008h /
0008h
Firmware Hub 0 boot
error Y
FWH1 Boot Err Boot Error (1Eh) / Sensor-
specific 0008h /
0008h /
0008h
Firmware Hub 1 boot
error Y
Pwr Good Power supply (08h) / OEM
(77h) 0000h /
0000h /
18B7h Statuses of all power
lines N
Pwr Good Evt Power supply (08h) / OEM
(77h) 0000h /
18B7h /
18B7h
Power fail events for
all power lines Y
Board NMI Critical interrupt (13h) /
Digital discrete (03h) 0002h /
0000h /
0003h CPU NMI signal N
SMI Timeout Critical interrupt (13h) /
Digital discrete (03h) 0002h /
0000h /
0003h
Time out during SMI
processing N
Lan Front0 Lk LAN (27h) / Sensor-
specific 0000h /
0000h /
0003h
LAN Front link status
or LAN port 8 status
(if supported by the
module)
N
Lan Front1 Lk LAN (27h) / Sensor-
specific 0000h /
0000h /
0003h LAN port 9 status (if
supported by the
module) N
Lan AMC0 Link LAN (27h) / Sensor-
specific 0000h /
0000h /
0003h
LAN port 0 status N
Lan AMC1 Link LAN (27h) / Sensor-
specific
0000h /
0000h /
0003h
LAN port 1 status N
Health Error Platform Alert (24h) /
Digital discrete (03h) 0000h /
0000h /
0003h
Aggregate states
(power, temperatures
etc.). Visualization
by the Health LED.
Y
MMC Reboot Platform Alert (24h) /
Digital discrete (03h) 0002h /
0000h /
0003h
MMC reboot active
state. Is asserted
during boot time.
N
Ver change Version change (2Bh) /
Digital discrete (03h) 0002h /
0000h /
0003h Version change N
Proc hot>100C OEM (CFh) / Digital
discrete (03h) 0002h /
0000h /
0003h
Monitors the CPU’s
“Processor Hot“
signal ( > 100 C)
N
