IPMI Firmware User Guide: AM4010
ModuleHotSwap
OEM (F2h) / Sensor-
specific
0007h /
0000h /
0007h
Hot swap sensor
N
IPMBL State
OEM (C3h) / Sensor-
specific
000Fh /
0000h /
000Fh
State of IPMB-L bus
N
Storage Err
Management subsystem
health (28h) / Sensor-
specific
0002h /
0000h
Storage error
N
Board Reset
OEM (C4h) / Sensor-
specific
04DEh /
0000h
Board reset event
Y
Board 3.3V
Voltage (02h) / Threshold (
01h)
2204h /
2204h /
1212h
Board 3.3V supply
Y
Board 3.3vIPM
Voltage (02h) / Threshold (
01h)
2204h /
2204h /
1212h
AMC Management
Power (MP) 3.3V
Y
Board 12.0v
Voltage (02h) / Threshold (
01h)
2204h /
2204h /
1212h
AMC Payload Power
(PWR) 12V
Y
Board 1.8V
Voltage (02h) / Threshold (
01h)
2204h /
2204h /
1212h
Board 1.8V supply
Y
Board Vtt0.9V
Voltage (02h) / Threshold (
01h)
2204h /
2204h /
1212h
DDR termination
supply
Y
Board 5.0V
Voltage (02h) / Threshold (
01h)
2204h /
2204h /
1212h
Board 5V supply
Y
Board 1.5V
Voltage (02h) / Threshold (
01h)
2204h /
2204h /
1212h
Board 1.5V supply
Y
Temp CPU
Temperature (01h) /
Threshold (01h)
0280h /
3280h /
1818h
CPU die temperature
Y
Temp MCH
Temperature (01h) /
Threshold (01h)
0280h /
3280h /
1818h
MCH die temperature
Y
Temp CPU In
Temperature (01h) /
Threshold (01h)
0280h /
3280h /
1818h
Inlet temperature
near CPU
Y
Temp AMC Out
Temperature (01h) /
Threshold (01h)
0280h /
3280h /
1818h
Outlet temperature
near AMC connector
Y
Temp AMC In
Temperature (01h) /
Threshold (01h)
0280h /
3280h /
1818h
Inlet temperature
near AMC connector
Y
Temp CPU Out
Temperature (01h) /
Threshold (01h)
0280h /
3280h /
1818h
Outlet temperature
near CPU
Y
CPU status
Processor (07h) / Sensor-
specific (6Fh)
0002h /
0002h /
0002h
CPU thermal alarm
sensor
N
