Slot Connectors
KTQM87/mITX Users Guide
MiniPICe with mSATA & USB2.0 (J13)
Slot J13 supports
mPCIe or mSATA cards (uses SATA5 Port) and USB2.0. The USB does support WAKE
function.
Note 1: 10K ohm pull-up to 3V3.
Note 2: 2K2 ohm pull-up to 3V3 Dual.
Note Type
Signal
PIN
Signal
Type
Note
WAKE#
1
2
+3V3
PWR
NC
NC
3
4
GND
PWR
NC
NC
5
6
+1.5V
PWR
1
CLKREQ#
7
8
NC
NC
PWR
GND
9
10
NC
NC
PCIE_mini CLK#
11
12
NC
NC
PCIE_mini CLK
13
14
NC
NC
PWR
GND
15
16
NC
NC
SUS_CLK
17
18
GND
PWR
NC
NC
19
20
W_Disable#
2
PWR
GND
21
22
RST#
SATA4_RXP
23
24
+3V3
PWR
SATA4_RXN
25
26
GND
PWR
PWR
GND
27
28
+1.5V
PWR
PWR
GND
29
30
SMB_CLK
SATA4_TXN
31
32
SMB_DATA
SATA4_TXP
33
34
GND
PWR
PWR
GND
35
36
U_USB13N
IO
PWR
GND
37
38
U_USB13P
IO
PWR
+3V3
39
40
GND
PWR
PWR
+3V3
41
42
NC
NC
SATA_DET4#
43
44
NC
NC
CL_CLK
45
46
NC
NC
CL_DATA
47
48
+1.5V
PWR
CL_RSTB
49
50
GND
PWR
W_DISABLE_N
51
52
+3V3
PWR
