On-board and Mating connectors
KTQ87/KTH81 Users Guide
9
On-board - & mating connector types
The Mating connector(s) / Cable Kits(s) which are fitting the On-board connectors are listed in below table.
The highlighted cable kits are included in the “KTQ87 Cable & Driver Kit” PN 826602 / 0200000002.
(Different quantity of each cable kit included, depending on the quantity of onboard connectors).
Connector
On-board Connectors
Mating Connectors / Cables
Manufacturer
Type no.
Manufacturer
Type no.
CPU_FAN
Foxconn
HF0804E-M2
AMP
1375820-4 (4-pole)
SYS_FAN1
SYS_FAN2
Mighty
21-013-00222-1
AMP
1375820-3 (3-pole)
KBD/MSE
Molex
22-23-2061
Molex
22-01-2065
SATA
FOXCONN
LD1807V-S5BA1DH
Molex
67489-8005
WINNING
WATM-
7DBN4B2B8UW4
Kontron
PN 821035 (cable)
ATX24P
CVILUX
CP-01324130
Molex
5557-24R
ATX4P
CHERNGWEEI
CR-W421S-24
Molex
39-01-2045
LVDS
Don Connex
C44-40BSBC1-G
Don Connex
A32-40-C-G-B-1
SAMTEC
SHF-120-01-F-D-
SM-K-TR
Kontron
KT 910000005
Hon Kon
Technology inc
HB12-220-VFS-20
Kontron
KT 821515 (cable)
Kontron
KT 821155 (cable)
COM1,2
CHERNGWEEI
CHEB254010S
Molex
90635-1103
Kontron
PN 821017 (cable)
Kontron
PN 821016 (cable)
USB4/5
FOXCONN
HC1105H-P9
Kontron
PN 821401 (cable)
USB10/11 *
(FRONTPNL)
-
Kontron
PN 821401 (cable)
LPC
PINREX
210-92-10GB04
-
-
Always On
Load default
CVILUX
CH11032VA00
-
-
Front Speaker
SPDIF
CHERNGWEEI
P101-SGN-
060/030-03
-
-
SPI
CHERNGWEEI
P201-SGN-060/030-12
-
-
FRONTPNL
PINREX
510-90-24GB03
Molex
90635-1243
Kontron
PN 821042 (cable)
FEATURE
PINREX CH74442V100
Don Connex
A05c-44-B-G-A-1-G
Kontron
PN 1052-5885
(Cable)
* USB10/USB11 is located in FRONTPNL connector. Depending on application KT TBD cable kit can be used.
Note: In above table, more than one connector can be listed for each type of on-board connector, if they
all have same fit, form and function and are approved by Kontron as an alternative. Please notice that
standard connectors like DP, PCI, PCIe, miniPCIe, Audio Jack, Ethernet and USB are not included in the list.
