System Specification
KTQ87/KTH81 Users Guide
3.2
System overview
The block diagram below shows the architecture and main components of the KTQ87 / KTH81. The key
component on the board is the Intel
®
Q87/H81 (Lynx Point) Desktop Platform controller Hub
Intel
Processor
HASWELL
LGA1150
240 pins DDR3 UDIMM Dual Channel,
PC3 10600/12800:
2 slots, 1-16GB total.
4 slots, 1-32GB total (KTQ87/Flex).
PCIe x16 (x16slot) Graphics
LVDS / DP (DisplayPort 1.2):
2x DP (KTH81/mitx)
3x DP (KTQ87/mitx)
DP + DP or LVDS (KTH81/Flex)
2x DP + DP or LVDS (KTQ87/Flex)
Embedded
Controller
ITE8516
Intel
PCH
Lynx Point
Q87/H81
SPI BIOS Flash (64MBit)
Feature connector:
SMBus/I2C
GPIO/DAC/ADC/PWM
GPIO expansion (up to 152)
Intruder detection
Fans: CPU, System, System2 (flex)
6-pin PS/2 Keyboard/Mouse
2x COM (RS232)
TPM (Infineon)
LAN2 Intel Pearsonville
LAN1 Intel Clarkville
Audio Codec VIA VT1708S:
2x3 Audio Jack
SPDIF Out
Line-Out
Frontpanel: Line-out2 & Mic2
PCIe x2 (x16slot) (KTH81/Flex)
PCIe x4 (x16slot) (KTQ87/Flex)
PCIe x1 (Flex)
mPCIe w. & USB2.0 (mITX)
SATA
3.0
SATA
2.0
mSATA
3.0
KTH81/mITX 1x
2x
1x
KTQ87/mITX 5x
-
1x
KTH81/Flex 2x
2x
-
KTQ87/Flex
6x
-
-
Raid 0/1/5/10 (Q87)
mSATA w. LPC Debug & USB2.0
IO area
Int.
USB
3.0/
2.0
2.0 2.0
KTH81/mITX 2x
2x 6x
KTQ87/mITX 4x
-
6x
KTH81/Flex 2x
2x 6x
KTQ87/Flex
4x
-
8x
