KTD-N0882-H Page 61 Slot Connectors
KTQ87/KTH81 Users Guide
8.2 mSATA (MSATA)
(mITX boards only).
The mSATA port (in mPCIe express connector) supports mSATA and USB 2.0 cards (not PCIe cards).
Note 1: 10K ohm pull-up to 3V3 Dual.
Note 2: 2K2 ohm pull-up to 3V3 Dual.
Note Type Signal PIN Signal Type Note
WAKE# 1 2 +3V3 PWR
NC NC 3 4 GND PWR
NC NC 5 6 +1.5V PWR
1 CLKREQ# 7 8 NC NC
PWR GND 9 10 NC NC
PCIE_mini CLK# 11 12 NC NC
PCIE_mini CLK 13 14 NC NC
PWR GND 15 16 NC NC
NC NC 17 18 GND PWR
NC NC 19 20 W_Disable# 2
PWR GND 21 22 RST#
PCIE_RXN 23 24 +3V3 Dual PWR
PCIE_RXP 25 26 GND PWR
PWR GND 27 28 +1.5V PWR
PWR GND 29 30 SMB_CLK
PCIE_TXN 31 32 SMB_DATA
PCIE_TXP 33 34 GND PWR
PWR GND 35 36 U_USB9N IO
NC NC 37 38 U_USB9P IO
NC NC 39 40 GND PWR
NC NC 41 42 NC NC
NC NC 43 44 NC NC
NC NC 45 46 NC NC
NC NC 47 48 +1.5V PWR
NC NC 49 50 GND PWR
NC NC 51 52 +3V3 PWR
