ISSPRO R6535M - Manual (Page 4)

Form No. IS016 (10/21/02 Rev. B) Page 4 of 5
Dip Switch Settings for Programmable Tachometers
Full Scale Deflection 3500 RPM
Dip Switch Settings Dip Switch Settings Pulses/
Rotation
FSD Freq @
3500RPM(HZ) 1 2 3 4 5 6 7 8 9 10
Pulses/
Rotation
FSD Freq @
3500RPM(HZ) 1 2 3 4 5 6 7 8 9 10
121 7259 0 0 0 1 0 1 0 1 1 0 181 10558 0 1 0 1 1 1 1 0 0 1
122 7117 1 1 0 1 0 1 0 1 1 0 182 10617 1 0 1 1 1 1 1 0 0 1
123 7175 1 1 1 1 0 1 0 1 1 0 183 10675 1 0 0 0 0 0 0 1 0 1
124 7234 0 1 0 0 1 1 0 1 1 0 184 10733 0 0 1 0 0 0 0 1 0 1
125 7292 0 1 1 0 1 1 0 1 1 0 185 10792 0 0 0 1 0 0 0 1 0 1
126 7350 1 0 0 1 1 1 0 1 1 0 186 10850 1 1 0 1 0 0 0 1 0 1
127 7409 1 0 1 1 1 1 0 1 1 0 187 10908 1 1 1 1 0 0 0 1 0 1
128 7467 0 0 0 0 0 0 0 1 1 0 188 10967 0 1 0 0 1 0 0 1 0 1
129 7525 0 0 1 0 0 0 1 1 1 0 189 11025 0 1 1 0 1 0 0 1 0 1
130 7584 1 1 1 0 0 0 1 1 1 0 190 11083 1 0 0 1 1 0 0 1 0 1
131 7642 1 1 0 1 0 0 1 1 1 0 191 11142 1 0 1 1 1 0 0 1 0 1
132 7700 0 1 1 1 0 0 1 1 1 0 192 11200 0 0 0 0 0 1 0 1 0 1
133 7759 0 1 0 0 1 0 1 1 1 0 193 11258 0 0 1 0 0 1 0 1 0 1
134 7817 1 0 1 0 1 0 1 1 1 0 194 11317 1 1 1 0 0 1 0 1 0 1
135 7875 1 0 0 1 1 0 1 1 1 0 195 11375 1 1 0 1 0 1 0 1 0 1
136 7934 0 0 1 1 1 0 1 1 1 0 196 11433 0 1 1 1 0 1 0 1 0 1
137 7992 0 0 0 0 0 1 1 1 1 0 197 11492 0 1 0 0 1 1 0 1 0 1
138 8050 1 1 0 0 0 1 1 1 1 0 198 11550 1 0 1 0 1 1 0 1 0 1
139 8109 1 1 1 0 0 1 1 1 1 0 199 11608 1 0 0 1 1 1 0 1 0 1
140 8167 0 1 0 1 0 1 1 1 1 0 200 11667 0 0 1 1 1 1 0 1 0 1
141 8225 0 1 1 1 0 1 1 1 1 0 201 11725 0 0 0 0 0 0 1 1 0 1
142 8284 1 0 0 0 1 1 1 1 1 0 202 11783 1 1 0 0 0 0 1 1 0 1
143 8342 1 0 1 0 1 1 1 1 1 0 203 11842 1 1 1 0 0 0 1 1 0 1
144 8400 0 0 0 1 1 1 1 1 1 0 204 11900 0 1 0 1 0 0 1 1 0 1
145 8459 0 0 1 1 1 1 1 1 1 0 205 11958 0 1 1 1 0 0 1 1 0 1
146 8517 1 1 1 1 1 1 1 1 1 0 206 12017 1 0 0 0 1 0 1 1 0 1
147 8575 1 1 0 0 0 0 0 0 0 1 207 12075 1 0 1 0 1 0 1 1 0 1
148 8634 0 1 1 0 0 0 0 0 0 1 208 12133 0 0 0 1 1 0 1 1 0 1
149 8692 0 1 0 1 0 0 0 0 0 1 209 12192 0 0 1 1 1 0 1 1 0 1
150 8751 1 0 1 1 0 0 0 0 0 1 210 12250 1 1 1 1 1 0 1 1 0 1
151 8808 1 0 0 0 1 0 0 0 0 1 211 12308 1 1 0 0 0 1 1 1 0 1
152 8867 0 0 1 0 1 0 0 0 0 1 212 12367 0 1 1 0 0 1 1 1 0 1
153 8925 0 0 0 1 1 0 0 0 0 1 213 12425 0 1 0 1 0 1 1 1 0 1
154 8983 1 1 0 1 1 0 0 0 0 1 214 12483 1 0 1 1 0 1 1 1 0 1
155 9042 1 1 1 1 1 0 0 0 0 1 215 12542 1 0 0 0 1 1 1 1 0 1
156 9100 0 1 0 0 0 1 0 0 0 1 216 12600 0 0 1 0 1 1 1 1 0 1
157 9158 0 1 1 0 0 1 0 0 0 1 217 12658 0 0 0 1 1 1 1 1 0 1
158 9217 1 0 0 1 0 1 0 0 0 1 218 12717 1 1 0 1 1 1 1 1 0 1
159 9275 1 0 1 1 0 1 0 0 0 1 219 12775 1 1 1 1 1 1 1 1 0 1
160 9333 0 0 0 0 1 1 0 0 0 1 220 12833 0 1 0 0 0 0 0 0 1 1
161 9392 0 0 1 0 1 1 0 0 0 1 221 12892 0 1 1 0 0 0 0 0 1 1
162 9450 1 1 1 0 1 1 0 0 0 1 222 12950 1 0 0 1 0 0 0 0 1 1
163 9508 1 1 0 1 1 1 0 0 0 1 223 13008 1 0 1 1 0 0 0 0 1 1
164 9567 0 1 1 1 1 1 0 0 0 1 224 13067 0 0 0 0 1 0 0 0 1 1
165 9625 0 1 0 0 0 0 1 0 0 1 225 13125 0 0 1 0 1 0 0 0 1 1
166 9683 1 0 1 0 0 0 1 0 0 1 226 13183 1 1 1 0 1 0 0 0 1 1
167 9742 1 0 0 1 0 0 1 0 0 1 227 13242 1 1 0 1 1 0 0 0 1 1
168 9800 0 0 1 1 0 0 1 0 0 1 228 13300 0 1 1 1 1 0 0 0 1 1
169 9858 0 0 0 0 1 0 1 0 0 1 229 13358 0 1 0 0 0 1 0 0 1 1
170 9917 1 1 0 0 1 0 1 0 0 1 230 13417 1 0 1 0 0 1 0 0 1 1
171 9975 1 1 1 0 1 0 1 0 0 1 231 13475 1 0 0 1 0 1 0 0 1 1
172 10033 0 1 0 1 1 0 1 0 0 1 232 13533 0 0 1 1 0 1 0 0 1 1
173 10092 0 1 1 1 1 0 1 0 0 1 233 13592 0 0 0 0 1 1 0 0 1 1
174 10150 1 0 0 0 0 1 1 0 0 1 234 13650 1 1 0 0 1 1 0 0 1 1
175 10208 1 0 1 0 0 1 1 0 0 1 235 13708 1 1 1 0 1 1 0 0 1 1
176 10267 0 0 0 1 0 1 1 0 0 1 236 13767 0 1 0 1 1 1 0 0 1 1
177 10325 0 0 1 1 0 1 1 0 0 1 237 13825 0 1 1 1 1 1 0 0 1 1
178 10383 1 1 1 1 0 1 1 0 0 1 238 13883 1 0 0 0 0 0 1 0 1 1
179 10442 1 1 0 0 1 1 1 0 0 1 239 13942 1 0 1 0 0 0 1 0 1 1
180 10500 0 1 1 0 1 1 1 0 0 1 240 14000 0 0 0 1 0 0 1 0 1 1
