M A I N T E N A N C E M A N U A L

Service and Maintenance

Service Procedure

Close the outlet shutoff valve, then close the inlet shutoff valve. Bleed

residual pressure from the assembly by opening the #4, #3, and # 2 test

cocks in this sequence.

General

1. Detailed maintenance manuals are available from your local FEBCO

representative.

2. Rinse all parts with clean water prior to reassembly.
3. DO NOT USE ANY PIPE DOPE, OIL, GREASE OR SOLVENT ON ANY

PARTS unless instructed to do so.

4. Do not force parts. Parts should fit together freely. Excess force may

cause damage and render the assembly inoperable.

5. Carefully inspect seals and seating surfaces for debris or damage.
6. After servicing, repressurize the assembly and test to ensure proper

operation.

Check Valve Disassembly

1.

CAUTION: The cover retains the spring on 2

1

2

" - 3" (65 - 80mm) valve sizes.

Remove the cover capscrews uniformly while holding the cover in place.

Carefully reduce hand force on the cover to relieve spring compression.
The check module on the 4" - 10" (100 - 250mm) valve sizes retains the

spring. Unscrew the capscrews uniformly to avoid binding the cover in

the body bore. The spring will push the cover approximately

1

2

" off the

top of the body.

2. Lift the spring and check assembly 2

1

2

" - 3" (65 - 80mm) or check mod-

ule 4" - 10" (100 - 250mm) from the body.

3. Inspect and clean debris from the disc and seat ring. Replace any dam-

aged parts.

4. Use the reverse procedure to assemble. If necessary, apply a thin film

of FDA/NSF approved grease to cover the O-ring. Install the capscrews

and tighten in a uniform cross pattern.

Relief Valve Disassembly

1. Remove the capscrews holding the cover to the relief valve body, and

remove the cover.

2. Remove the diaphragm and pull the internal assembly from the body. It

may be helpful to push the internal assembly with your fingers through

the discharge opening.

3. Inspect for debris, damage or fouling of the seat disc. Clean or replace

the rubber disc as required.

4. Reposition the internal assembly and diaphragm into the body. Install

the cover and cap screws.

Field Test Procedure

FEBCO recommends the use of the appropriate test method presented in

the ASSE Series 5000 manual that is consistent with your local codes.

Troubleshooting

PROBLEM

CAUSE

SOLUTION

1. Continuous relief

a. Debris on check

Disassemble and clean

valve discharge

seating surfaces

b. Debris on relief valve

Disassemble and clean

seating surfaces

2. Intermittent relief

a. Inlet pressure fluctuations

Eliminate fluctuations

valve discharge

b. Downstream pressure

Eliminate surges

surges

3. Low flows passing

a. Mainline check fouled

Disassemble and clean

through mainline

b. Bypass line plugged

Disassemble and clean

valve (RPDA)

Note: The gap drain is not designed to catch the maximum discharge pos-

sible from the relief valve. The installation of FEBCO air gap with the drain

line terminating above a floor drain will handle any normal discharge or nui-

sance spitting through the relief valve. However, floor drain size may need

to be designed to prevent water damage caused by a catastrophic failure

condition. Do not reduce the size of the drain line from the air gap fitting.
