26 | Operation
Front Panel
Figure 6: HI-6100 Front Panel (shown with optional case)
The front panel of the HI-6100 includes:
 Display —Enables the user to see the active probe(s).
 Function keys (6) —Allow the user to easily navigate the menus of the
controller.
 Power button —Includes an indicator light allowing the user to easily
verify if the unit is on or off.
To turn off the HI-6100, press and hold the power button for three to
four seconds.
HI-6100 Menu Options
On the page 27 is an illustration of the HI-6100 menu hierarchy. The illustration
serves as an overview or map of the menu options; the remainder of this chapter
describes each option.
