ETS-Lindgren HI-2790B Calibration Comparison System - Manual (Page 39)

www.ets-lindgren.com Specifications 39
9.0 Specifications
Frequency: 2450 + 0.1 MHz over an ambient
temperature range of 20 degrees to
24 degrees C
Frequency Stability: 50 ppm/°C + 0.0025%
Dynamic Range: 0.1 – 5 + mW/cm 2
Plane-wave equivalent power
density at probe test location.
Input Power: 100 – 240 VAC
0.8 – 0.4 A max
50 – 60 Hz
Fuses: 250 Volt, 1.0 Amp, Type T
(5 mm x 20 mm)
Output: 2450 MHz, 4 W max
Do not operate without 50 ohm load.
Local Calibration Reference: HI-1710 Microwave Survey System
(HI-1710 LCR)
Size:  Width: 770 mm wide
 Depth: 1040 mm deep
 Height: 1230 mm high
(1360 mm with HI-2790B
Power/Control Module)
Weight: 45 kg (shipping)
Support: Castor wheels for ease of location
