3.0 Setup
CAUTION: Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your shipment.
Connecting Components
See HI-2790B Calibration Comparison System Block Diagram on page 8 for a
description of connections.
1. Connect the HI-2790B Power/Control Module and the
HI-1710 Microwave Survey Meter (HI-1710 LCR) to the mains power
supply.
Note: Some models of the HI-1710 LCR provide a voltage setting
switch at the power input to select 115 or 220 VAC input voltage.
2. Plug the IN connection port on the flexible coax cable assembly into
the RF output connector on the HI-2790B Power/Control Module.
3. Plug the RF coax cable into the input connector on the waveguide.
