4.0 Operation
CAUTION: Before placing into operation, follow the safety
information in the ETS-Lindgren Product Information
Bulletin included with your shipment.
Description of Controls
The following controls on the HI-2790B Power/Control Module allow the control,
adjustment, and monitoring of all functions of the HI-2790B Calibration
Comparison System.
Control Function
POWER Turns unit on and off.
RF Turns RF power to the test chamber on and off.
RF LEVEL Adjusts power level up and down.
CAL Sets HI-2790B Power/Control Module to
calibration mode. This mode adjusts the
RF Power display to read a calibrated value that
matches the reading on the HI-1710 LCR.
DISPLAY SELECT Selects the Operating menu or the
Status menu.
UP / DOWN Steps the display through the selected menu.
