Assembly and Installation | 15
4.0 Assembly and Installation
Before connecting any components, follow the safety information
in the ETS-Lindgren Product Information Bulletin included with
your shipment.
The Model 2175 MiniMast™ is shipped partially assembled; the assembly
process will take approximately one hour. Ensure that a clear area is available to
unpack and assemble the MiniMast. Prior to starting the assembly process, open
the shipping container and check all parts for any shipping damage.
Do not discard any packing material until the MiniMast is fully installed and
operation. During this assembly procedure, refer to the illustrations provided
for each step.
Tools needed for assembly (included with shipment):
• Adjustable open-end wrench
• Phillips head #2 screwdriver
Figure 1: Tools shipped with MiniMast
