Specifications | 13
3.0 Specifications
Electrical Specifications
Nominal AC Voltage 220 VAC
Input Frequency 50/60 Hz
Current Rating 10 Amp service
Phase Single
Physical Specifications
Base Dimensions
0.90 m x 0.90 m
2.95 ft x 2.95 ft
Weight 81.2 kg (179.0 lb)
Overall Height 4.61 m (15.1 ft)
Mast Height Nominal 4.5 meters
Scan Range
4 meters standard
Custom height may be specified upon
placement of order
Required Air Pressure 60-80 psi (410-550 kPa)
Carrier Load Rating Not to exceed 18 kg (40 ft lb)
Maximum Loading
10 kg (22 lb)
See Operation on page 27 for additional
information
