26 | Optional Shaft Kit Installation Instructions
2. Loosen the three 3/8–16 hex head screws on the gearbox coupling
before insertion. Place the 1/4-in diameter x 1-in long dowel pin into the
groove of the drive shaft, and line the shaft and pin up with the groove in
the coupling. With everything aligned, push the shaft and pin into the
coupling. Leave approximately a 1/4-in gap between the 6.01-cm
(2.37-in) diameter shaft shoulder and the end of the coupling. Slowly
tighten the three screws on the coupling.
3. If the mid-floor support was not required because DIM1 was less than
3035 mm (9.9 ft), skip to step 5. Otherwise, continue to the next step.
4. If the second shaft housing is required, slip it around the shaft, into the
mid-floor support, and then clamp it in place. Only the one bushing that
was installed previously is needed in this support. There should be one
remaining bushing, and that will be used in the next step.
5. Install the remaining bushing and mid-floor support onto the motor drive
end of the shaft housing. Guide the 2.54-cm (1-in) diameter end of the
shaft through the white bushing. The end of the shaft should stick out of
the bushing approximately 5.08 cm (2.0 in). Make sure the housing
extends out square with the base of the table for proper alignment.
Connect Shaft to Motor Drive
1. Install the hose coupling onto the steel shaft of the motor drive unit. The
two hose clamps provided should rest loosely around the hose.
2. Position the motor drive on the floor and slide the unit into place with the
hose coupling connecting both shafts. Bolt the aluminum tie bracket into
place, and install one hose clamp onto the steel drive shaft and one onto
the plastic shaft.
3. Fasten the floor supports and motor drive unit to the floor using 5/16-in
diameter screws through the mounting holes in the bottom base of the
shaft supports and motor drive.
4. Reinstall the gearbox cover using four 3/8-16 x 1-in hex screws. Be
careful not to over-tighten the plastic bolts.
5. If desired, cables can be run along a slot under the base of the turntable,
up and through the opening at the center of the table. The slot is 1 cm
(0.40 in) deep and 2.54 cm (1 in) wide. It should accept a cable up to
3/8-in diameter.
